Help CenterDZ Series Presser
Related Products
Specifications
1.DZ series presser2.More reasonable, has good property and effect.
3.Large output,stable in operation,low noise
Description
This machine is a new type one developed by our company on the foundation of absorbing foreign advanced technology. The design is more reasonable, has good property and effect.
Take the example of distiller’s grain, compare with drier, electricity consumption: 1:12, area: 1:10,
Investment: 1:4.
Principle
The material is paved evenly on belt distributing device, it could removing most of moisture and discharging from rear after pressing, displacing and cutting by several ‘S’ shape press rollers.
Features
From feeding to discharging with high degree continuous automation.
Being adapted pneumatic tensioning system and cylinder automatically rectify a deviation.
Using different structure of filtering belt according to different material.
Washing device as option by requirement, could guarantee dehydration effect of filtering belt.
Condensating-preprocessing-device as option by requirement, could improve productive efficiency.
The machine is large in output, stable in operation, low noise, saving energy with good dehydration effect.
Applications
It is widely used for Aztec marigold industry, sludge, printing industry, papermaking, food, chemical industry and so on.
Technical Parameter
|
Specification
Type |
Width of filter belt (mm) |
Power of motor (kw) |
Tension of filter belt (kn/m) |
Speed of filter belt (m/min) |
Pressure (Mpa) |
DZ1000 |
1000 |
1.1 |
0-8 |
1-8 |
0.3-0.5 |
DZ1500 |
1500 |
1.5 |
|||
DZ1800 |
1800 |
2.2 |
|||
DZ2000 |
2000 |
2.2 |
|||
DZ2500 |
2500 |
2.2 |
|||
DZ3000 |
3000 |
3 |
