Deformed Wire Straight Line Wire Drawing Machine
US$ 20,000 - 80,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or as u need
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
CNC or Not
Normal
Place of Origin
Jiangsu, China
Brand Name
wanyi
Model Number
LZ600 drawing machine
Voltage
380V
Power(W)
80KW about
Dimension(L*W*H)
10.5X1.4X.1.45M
Weight
8000KG
Certification
third parts
Warranty
ONE YEAR FREELY
After-sales Service Provided
Overseas service center available
Specification
| Items | Unit | LZ9-12/1200 | LZ10/800 | LZ9/700 | LZ10/560 | LZ10/400 | ||
| Reel diameter | mm | 900 | 800 | 700 | 560 | 400 | ||
| Draw passage | time | 9-12 | 10 | 9 | 10 | 10 | ||
| Incoming dia | mm | Φ14-8 | Φ10-8 | Φ8-6.5 | Φ6.5-5.5 | Φ14-8 | ||
| Outgoing dia | mm | Φ5-3 | Φ4-3 | Φ3-2.5 | Φ2-1.8 | Φ1-0.8 | ||
| Wire darwing line | m/min | 300 | 360 | 480 | 720 | 840 | ||
| Incoming strength | Mpa | ≤1300 | ≤1300 | ≤1300 | ≤1300 | ≤1300 | ||
| Total compressibility | % | 87.24-85.94 | 84-85.94 | 85.94-85.21 | 90.53-89.29 | 87.24-84 | ||
| Average compressibility | % | 20.48-19.58 | 18.42-19.58 | 19.58-19.13 | 21.00-0.02 | 18.61-16.74 | ||
| Single motor power | Kw | 110-90 | 90-55 | 75-55 | 37-22 | 15-7.5 |
Note: We can design the wire drawing machine according to customers' requirement..
