Reinforcing Wire Drawing Machine
US$ 30,000 - 40,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or as u need
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Tyre Steel Wire Drawing MachineUS$ 20,000 - 50,000MOQ: 1 Set -
Spring Steel Straight Line Wire Drawing MachineUS$ 20,000 - 60,000MOQ: 1 Set
-
Umbrella Steel Wire Drawing MachineUS$ 20,000 - 50,000MOQ: 1 Set
-
Hard Alloy/NiCr Alloy Steel Wire Drawing MachineUS$ 20,000 - 50,000MOQ: 1 Set
-
Advanced Straight Line Wire Drawing MachineUS$ 30,000 - 60,000MOQ: 1 Set
Condition
New
CNC or Not
Normal
Place of Origin
Jiangsu, China
Brand Name
wanyi
Model Number
LZ6/400
Voltage
220/380V
Power(W)
11KW each
Dimension(L*W*H)
Optional
Weight
7000kg
Certification
CE SGS ISO9001
Warranty
one year
After-sales Service Provided
Overseas service center available
Straight wire drawing machine
1. The material of the inlet wire:low carbon steel,high carbon wire,
2. The max strength of the inlet wire: 1000Mpa
3. Max diameter of the inlet wire:Ø2.4mm
4. The outlet wire diameter: Ø0.84mm
5. Max speed:16m/s
6. water pressure:≥0.2Mpa
7. air- pressure:≥0.4Mpa
8. The Motor of the drawing machine: 11KW adjustable frequency motor.
