| Item | Parameter | ||
Dimension Parameter | Overall dimension (L×W×H mm) | 3250 ×1130×2130 (including the sweeping brushes); | |
2970×1130×2130mm (excluding the sweeping brushes) | |||
| Wheel tread (mm) | 890 | ||
| 890 | |||
| Wheelbase (mm) | 1200 | ||
| Front suspension (mm) | 1100 (including the sweeping brushes) | ||
| 820 (excluding the sweeping brushes) | |||
| Rear suspension (mm) | 950 | ||
| Approach angle | 11° | ||
| Departure angle | 16° | ||
| Minimum ground clearance (mm) | 120 | ||
| Weight | Curb weight (kg) | 1450 | |
Parameter (kg) | Unladen weight distributed to the front axle (kg) | 640 | |
Unladen weight distributed to the rear axle (kg) | 810 | ||
Laden weight distributed to the front axle (kg) | 1850 | ||
Laden weight distributed to the rear axle (kg) | 1000 | ||
Performance Parameter | Size of the garbage bin (L) | 240 | |
| Available load capacity(kg) | 400 | ||
| Maximum sweeping width (m) | 1.8 | ||
| Operating speed (km/h) | 0-10 | ||
| Running speed (km/h) | 0-16 | ||
| Maximum suction density(g/cm3) | 2.7 | ||
| Maximum suction fineness (mm) | 45 (the equivalent diameter with the suction density of 2.7g/cm3). | ||
| Maximum sweeping capacity (m2/h) | 18000 | ||
| Sweeping efficiency | ≥95% | ||
| Operating temperature | 0~50℃; -25~50℃(for dry sweeping or sweeping with snow-melting agent) | ||
| Rated passenger capacity | 1 | ||
| Uninterrupted operating time (h) | 4 (depending on the amount of the water sprayed and the amount of garbage collected) | ||
| Minimum turning radius(mm) | 2150 | ||
| Maximum gradeability | 20% | ||
| Clean water tank volume(L) | 140 | ||
| Fuel tank volume(L) | 46 | ||
| Operating fuel consumption (L/h) | ≤2 | ||
| Noise (dB(A)) | ≤78 | ||
| Running | Driving mode | 4×2 front-wheel drive | |
| Parameter | Transmission mode | Hydrostatic continuously variable transmission | |
| Tyre model | 23×8.5-12 | ||
| Wheel quantity | 4 | ||
| Tyre pressure (bar) | 2 | ||
| Wheel rim | 12×7 | ||
| Torque of the wheel nut (Nm) | 90 | ||
Engine Parameter | Brand | Kubota | |
| Type | Three-cylinder, four-stroke, direct injection diesel engine with water-cooling system | ||
| Model | D1105 | ||
| Displacement (cm3) | 1123 | ||
| Rated power/revolving speed | 18.1kW/2800rpm | ||
| Rated torque/ revolving speed | 70Nm/2200rpm | ||
| Operating revolving speed | 2000 (common operating condition)-2800 (enhanced operating condition) rpm | ||
| Fuel | 0# light diesel oil | ||
Steering System | Steering mode | Hinge connected | |
| Steering gear | Full-hydraulic steering gear | ||
| Steering mechanism | Composed of oil cylinder for the steering of the front and rear frames | ||
Hydraulic System | Type of hydraulic oil | HM46 anti-wear hydraulic oil; | |
YC-N68 low temperature-resistant anti-wear hydraulic oil suitable for the working temperature from -25 to -10℃. | |||
| Cleanness of hydraulic oil | Running circuit | Class 18/13 | |
| Operating circuit | Class 19/17 | ||
| Hydraulic oil tank volume | 35L (Total oil volume of the hydraulic system: 50L) | ||
Electric System | Formation | Circuit for running system and circuit for control system | |
| Voltage (V) | 12 | ||
| Capacity of the storage battery (Ah) | 70 | ||
Sweeping System | Form | Two disk like sweeping brushes are located on the two sides in the front of the street sweeper. | |
| Diameter of the sweeping brush (mm) | Φ650 | ||
Diameter of the base bracket of the sweeping brush (mm) | Φ420 | ||
Adjustable inclination angle range of the base bracket of the sweeping brush | 4~6° for front inclination; | ||
| 2~5° for exterior inclination | |||
| Suction | Diameter of the suction pipe (mm) | Φ150 | |
| System | Width of the suction nozzle (mm) | 500 | |
Hangzhou ICOM construction Machinery Co., Ltd. is a professional manufacturer of asphalt machines. Our sales and R&D team have over 10 years experience to focus on asphalt distributor, synchronous pavement surface vehicles and other road machinery and equipment . Based on innovation and expertise, we have received more than 10 patents, selling more than 20 countries and regions.Focus cast quality, intentions to win the trust. We will offer innovative, professional, practical asphalt machinery and equipment with the spirit of craftsman.
1. Methods of Payment:
T/T (Telegraphic Transfer) or Western Union or L/C at sight
2. MOQ:
No requirement for testing and trial order
3. Handling time for an order:
Within 10 days supplied from stock
4. Shipping way:
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.
5. Quality Control:
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.
6. After Services:
a. Our sales team will response for your question within 24 hours (Holidays Excluded)
b. Technical Support will be available in any time
c. Free replacement will provide once the failure confirmed caused by our product quality.
