Upper Bitumen Equipment Plant for Sale With Competitive Price

Name: Upper Bitumen Equipment Plant for Sale With Competitive Price
Brand: ICOM
SKU: 141292992
Availability: InStock

Hangzhou IKOM Construction Machinery Co., Ltd.

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

ICOM

Model Number:

ZM-8SPSZ

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name ICOM

Model Number ZM-8SPSZ

After-sales Service Provided Engineers available to service machinery overseas

Parameter

BITUMEN SPRAYER

Model	ZM-8SPSZ
Overall size (mm)	6600×2280×1960
Complete weight (kg)	4650
Tank size (mm)	3800×2020×1680
Tank volume (L)	8000
Engine model	YANMAR 3TNV82A-SNN
Power (kw/r/min)	15.3/2200
Hydraulic pump	CBQL-F525/F525-CFH-R
Burner	G20
Burner power (kw)	95-216
Volume of hydraulic oil tank (L)	150
Air compressor	V-0.12/8
Asphalt pump	QGB450
Asphalt pump motor	LY-A2F107W2P2
Heat transfer oil pump	40-25-160
Heat transfer oil pump	A2F16W6.1P3
Multi-way valve	ZS1-L20E-W-OO
Lift cylinder	HSGL01-63/45E-3101
Spray width (m)	2-5
Spray rate (L/m2)	0.25-3.0
Width of spray tube (m)	5
Number of nozzles (pc)	33
Nozzle type	Fan-shaped
Allowable viscosity of working medium (Cst)	≤300
Max. air pressure of cleaning system (MPa)	0.6
Max. air pressure of hydraulic system (MPa)	20
