Specifications: Pillow packing machine
Pillow packing machine
Application:
Biscuits, instant noodles, towels, bread, cakes, pies, candy, ice cream, medicine, commodity, hardware, industrial components etc.
Features:
1. Dual frequency conversion control, bag length can be set and cut on one step, saving time and film.
2. Interface features easy and quick setting and operation.
3. Self failure diagnosis, clear failure display.
4. High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
5. Temperature independent PID control, more suitable for packing different materials.
6. Positioned stop function, without sticking knife or wasting film.
7. Simple driving system, reliable working, convenient maintenance.
8. All control is realized through software, easy for function adjusting and technical upgrade.
Main Parameters:
Type |
TCZB-250X |
TCZB-350X |
Film Width |
Max.250mm |
Max.350mm |
Bag length |
65-280mm |
65-280mm |
Bag width |
30-110mm |
50-160mm |
Product height |
Max.40mm |
Max.45mm |
Film roll diameter |
Max.320mm |
Max.320mm |
Packing speed |
40-230 bag/min |
40-230 bag/min |
Power |
220V,50/60HZ,2.4KVA |
220V,50/60HZ,2.8KVA |
Machine size |
(L)3920×(W)670×(H)1320 |
(L)4020×(W)720×(H)1320 |
Machine weight |
800Kg |
900Kg |
Our advantages:
1. More than 10 years experience
2. Professional and international team
3. Top technology; highest quality
4. Open and innovative idea
5. Lifetime technical advice
