Specifications: Oil press 200A-3
Oil press 200A-3
Introduction:
The machine is applicable for the pressing of vegetable oil-bearing crops such as rapeseed, peanut kernel, sesame, cottonseed kernel, soybean, copra, teaseed, sunflowerseed, etc. In accordance of the request of customer, the pressing worms can be replaced for the pressing of ricebran.
Features:
1. The main parts main shaft, pressing worms, cage bars, gears, etc are made of high-quality alloy, and be surface hardened.
2. The meal is cooked and steamed in the cooker, according to different temperature requirement of different kind of seed, the temperature and water content can be regulated accordingly, so high quality oil can get.
3. From feeding to the outflowing of oil and cake, the machine is thorough automatic working, the maintenance is easy, and labor hand is saved.
Technology Data:
Oil Seed Name |
Capacity (kgs/24hrs) |
Oil Yield (%) |
Residual Oil in Dry Cake (%) |
|
Rape Seed |
9000-12000 |
33-38 |
6-7 |
|
Peanuts |
9000-10000 |
38-45 |
5-6 |
|
Sesame Seed |
6500-7500 |
42-47 |
7-7.5 |
|
Cotton Beans |
9000-10000 |
30-33 |
5-6 |
|
Soya Beans |
8000-9000 |
11-14 |
5-6 |
|
Sunflower Seed |
7000-8000 |
22-25 |
6-7 |
|
Rice Bran |
6000-7000 |
10-14 |
6-7 |
|
Specification of Machine | ||||
Item |
|
|||
Inside diameter of steaming kettle: |
φ1220mm |
|||
Stirring Shaft Speed |
35rpm |
|||
Steam Pressure |
5-6kgs/cm2 |
|||
Pressing Bore Diameter |
front sectionφ180mm; rear sectionφ152mm |
|||
Pressing Shaft Speed |
8rpm |
|||
Feeding Shaft Speed |
69rpm |
|||
Pressing time in bore |
2.5minutes |
|||
Seed Steaming and Roasting Time |
90minutes |
|||
Max. Temperature of Speed Steam and Roasting |
125-128℃ |
|||
Power Demand |
18.5KW |
|||
Overall Dimension (L*W*H) |
2850*1850*3270mm |
|||
Weight |
5000kgs |
|||
Note: | ||||
Our advantages:
1. More than 10 years experience
2. Professional and international team
3. Top technology; highest quality
4. Open and innovative idea
5. Lifetime technical advice
