Bucket Elevator of High Quality

Bucket Elevator of High Quality thumbnail-1
Bucket Elevator of High Quality photo-1
US$ 5,500 - 5,500 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
FAST
Contact Supplier Request Quote Chat Now
Jiangsu FAST Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name FAST
Model Number TDTG
Type Other, bucket elevator
Voltage 380V
Power(W) 15kw
Dimension(L*W*H) 2200*1000*1500mm
Weight 2000 kg
Certification ISO9001
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

 Bucket Elevator

Product Description



Bucket Elevator of high quality



Application:

TDTG Series Bucket Elevator is an important equipment for convenient vertical conveying. It can be used in processing industry or bulk storage. The capacity is up to 1500t/h. Powder and pellet material can be elevated to 80m. TDTG Series Bucket Elevator can provide excellent service for various sectors, including flourmill, animal feed plant, inland storage elevator (silo) or grain collection station.



Performance:



A large number of security devices, to achieve the best safety performance



→ Security devices include a zero-speed detector, a anti-deviation detector and a anti-kickback device to ensure the best monitor of performance when running;



→ Special design for special purpose, with positive or negative explosion protection and the anti-compression and anti-vibration barrel to provide best safety performance for different purposes.



Solid structure, easy to clean



→ solid structure and anti-resisting parts make it easy to clean and prolong the service life;



→ access door and split head in the top facilitate the maintenance——it is easy to clean and maintain.



optimized structure, highly flexible



→ Standard structure has one or more layers of powder coating, in addition, we also offer galvanized and stainless steel material which ensure the high flexibility of different materials and the installation indoors or outdoors.



→ optional circular base, can be used in the field of higher requirements for sanitation.





Technical parameter:



MODEL

POWER

(kw)

CAPACITY(t/h)

PELLET

POWDER

TDTG40/18

2.2~5.5

11~29

11~22

TDTG40/23

2.2~7.5

12~39

12~29

TDTG40/28

2.2~7.5

25~46

13~35

TDTG50/23

2.2~11

20~65

17~61

TDTG50/28

2.2~18.5

32~80

27~57

TDTG60/30

5.5~18.5

57~122

53~92

TDTG60/33

7.5~18.5

70~153

67~110

TDTG63/44

18.5~30

150~200

100~150



MODEL

CAPACITY(t/h)

PELLET

POWDER

TDTG63/57

200-300

150-180

TDTG80/57

300-400

150-200

TDTG80/80

400-500

200-300

TDTG80/98

500-600

300-400

TDTG100/119

600-800

400-500

TDTG100/136

800-1000

500-600

TDTG100/164

1000-1300

600-700

TDTG100/190

1300-1500

700-800

 Power is depend on the capacity and height



 Bucket Elevator of high qualityBucket Elevator of high qualityBucket Elevator of high qualityBucket Elevator of high quality





Company Information



Jiangsu Fasite Machinery Co., Ltd.is a high-tech enterprise professional integrated providing solution for feed, agricultural machinery and turn-key projects. It covers an area of 33000m2, among which of factory building is 20000m2 . Its registered capital is 10 million RMB and has invested 30 million during the first stage. There are various advanced processing equipments such as large imported laser cutting, machinery, bending machinery, conveying equipment, surface treatment and the electrostatic powder coating production line etc., which makes it manufacture quality a leading level in China.



 Bucket Elevator of high qualityBucket Elevator of high qualityBucket Elevator of high quality

Our Services



è  Standardized engineering installation
We have trained a professional installation team to avoid some malpractice due to outsourcing, so that the installation demands from customers can be met more quickly.



è  Mechanized technology reform

We have a high-efficient mechanization technical team, which can meet the technical renovation and temporary rush-repair task at any time.



è  Professional after-service

We are adhering to the idea "the management is law, the service is the morality" and makes a rapid response service system, so that our after-service and spare parts could be supplied to customers within 24 hours.
