Product Application
main processing of palm fruit processing :
a. Palm fruit reception:Transport FFB to reception station, flow to the scraper conveyer, conveyed to sterilizing station.
b. Sterilizaiton: FFB transported by scraper conveyer fall into sterilizing tank, make FFB soft,get more oil yield. sterilizing time 90~120mins, temperature 130~145°C
this is the sterilization tank:
Main Features
c.Threshing: After sterilizing, fruit bunch transported to thresh machine, separate palm fruit and empty fruit bunch.
d:Digesting: Before press palm fruit, should be crushed separated pulp and kernel
e.Oil press: After crushing and digesting, the maxture of palm fruit and kernel fall into special palm oil presser
f.Clarification:Filter the oil and use centrifuge to separate oil and impurities.
g. Kernel recovery:After press, the kernel and cake will be transported to kernel recovery station. Separating nut and shell, then go to kernel oil press.
h.Palm kernel oil filteration: Use vibrating filter to filter the oil to remove impurities in it.
Chinese palm fresh oil processing machinery manufacturer for edible oil mill.
this is the oil pressing station:
Machine Parts
Name: palm fruit digestor
Brand: BEST
Original: China
to break off the palm fruit, so that can press oil easily.
get higher oil yield.
direct steam inlet digester, to adjust moisture .
Main Features
Name: palm fruit oil press machine
Brand: BEST
Original: China
the palm fruit oil yield increase by adjusting material moisture and temperature in digesting tank,
oil press machine adopts hydraulic controlling systems to adjust the space between pressing bolts. suit for various palm fruits and ensure the oil yield.
Machine Parts
Name: threshing station
Brand: BEST
Original: China
to separat the palm bunches and plam fruit.
the palm fruit conveyed to the digesting tank.
it has strong structure and long life.
Main Features
Name: clarification station
Brand: BEST
Original: China
oil purifying system, using new technology . reduce the investment and can reduce oil loss below 1.3%.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
