China coarse salt and sugar screw concial mixing machine
Features of screw concial mixing machine:
TDZ double auger conical mixer is widely used on a variety of application in the industry such as food, chemical industry, pesticide, dyestuff, battery material, rare earth and other powder mixing ect. The application material can be: 304, 316L,321, carbon steel ect. The even mixing can be performed under 1 quarter to 1 hour. The features of this double screw conical mixer including:
1. for high standard mixing after full discharge without leftover.
2. softly mixing without damage to the fragile material;
3. effect of mixing under low energy and it is more adaptable to the reaction of chemical and physical
Picture of screw concial mixing machine:
Principle of working:
TDZ double auger conical mixer rotates around its axes according to right of two internal asymmetric spirals, which install in the cantilever; mean while, the rotational force from the cantilever drives two spiral making revolution around conical chamber axle wire.
Double auger conical mixer come into being 4 direction forces:
1. 2 inner asymmetric spirals upgrade the materials through rotation.
2. Tumbler with low-speed rotation makes materials circulate motion.
3. Rotation and revolution of spiral make materials absorbed while diffuse to circle direction;
4. 2 flows materials upward, then go down to the center, which come into being a downward material flow; this way can full the bottom gap and form a convective circulation.
Reference paramete of screw concial mixing machine:
| Type | Volume(L) | Coefficient | Power(KW) | Rotate speed(R/min) | Size(mm) | Weight |
| TDZ-200 | 200 | 0.4-0.6 | 2.75 | 2/108 | Φ990*H1100 | 350 |
| TDZ-300 | 300 | 0.4-0.6 | 3.25 | 2/108 | Φ1100*H1850 | 480 |
| TDZ-500 | 500 | 0.4-0.6 | 3.25 | 2/108 | Φ1180*H2220 | 600 |
| TDZ-1000 | 1000 | 0.4-0.6 | 4.75 | 2/57 | Φ1610*H270 | 1200 |
| TDZ-1500 | 1500 | 0.4-0.6 | 6.25 | 2/57 | Φ1900*H3200 | 1350 |
| TDZ-2000 | 2000 | 0.4-0.6 | 6.25 | 2/57 | Φ1970*H3450 | 1500 |
| If you need more technical parameters, please contact us. | ||||||
Packaging& Shipping
Our factory :
Our Exhibition :
FAQ:
screw concial mixing machine
