Powder auger filling machines / cans packaging machine
- 80 Unit / Units per Month
- shanghai
- T/T
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Chemical, Food, Medical | Packaging Type: | Case |
Packaging Material: | Wood | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | AC208-415V | Power: | 2.51kw | Place of Origin: | Shanghai, China |
Brand Name: | Tandy | Model Number: | DH-Q2-160 | Dimension(L*W*H): | 1840x1070x2420 |
Weight: | 350kg | Certification: | CE Certificate | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Powder auger filling machines / cans packaging machine
Descriptive abstract of filling machines:
This series could do work of measuring ,can holding , vibration and filling ,etc,it can constitute the whole set can filling work line with other related machines , and suitable for filling kohl, glitter powder ,pepper, cayenne pepper ,milk powder ,rice flour ,albumen powder ,soy milk powder ,coffee powder ,medicine powder ,additive ,essence and spice ,etc.
Main features of filling machine:
1. Stainless steel structure , level split hopper ,easily to wash.
2.Servo-motor drive auger. servo-motor controlled turntable with stable performance.
3.PLC,touch screen and weighing module control
4.With adustable height-adjustment handwheel at reasonablethe height, easy to adjust the head position.
5.With pneumatic can lifting device and vibrating device to assure the material not spilling out when filling.
6.Weight-chosen device , to assure each product be qualified, so to leave the latter cull eliminator.
7.To save all product's parameter formula for later use, save 10 sets at most.
8.When changing the auger accessories ,itis suitable for materials ranging from super fine powder to small granula.
main technical date of filling machines:
Model | DH-Q2-100 | DH-Q2-160 |
Container size | Φ20-100mm; H 15-150mm | Φ30-160mm; H 50-260mm |
Filling weight | 1-500g | 10-5000g |
Filling speed | 20-50 bottles/min | 20-40 bottles/min |
Filling accuracy | ≤100g , ≤±2%; 100-500g ,≤±1% | ≤500g , ≤±1%; >500g ,≤±0.5% |
Power supply | 3P AC208-415 50/60HZ | 3P AC208-415 50/60HZ |
Total power | 2.04kw | 2.51kw |
Total weight | 250kg | 350kg |
Air supply | 6kg/cm2, 0.05m3/min | 6kg/cm2, 0.05m3/min |
Overall dimension | 1400x830x2080mm | 1840x1070x2420mm |
Hopper volume | 35L | 50L |
Picture of filling machines :
