CE approved pig feed hammer mill
- 30 Set / Sets per Month
- qingdao
- T/T Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | HEXIE |
Model Number: | SFSP | Type: | Other, hammer mill | Voltage: | 220V/380V |
Power(W): | 22kw | Dimension(L*W*H): | 2200*1000*1500mm | Weight: | 50 kg |
Certification: | ISO9001 | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
CE approved pig feed hammer mill
63 SeriesApplied Range
SFSP Hammer Mill is mainly used to various granular raw materials, such as corn, sorghum, wheat, bean and others.Also can be used to fiber raw materials and raw material which contain more moisture and oiliness through the special design, is a key equipment of crushing section in feed mill.
Product features
Crushing chamber adopts advanced water body design, with a secondary crushing tooth plate, shaft end with the wind device, change the movement direction of the material, break effective circulation layer, to crush materials thoroughly, and accelerate the sieving of small particles, reduce temperature of the crushing chamber, thereby improving the output of this series of crusher;Motor frame integral milling, rotor dynamic balance processing, make the mill less vibration, lower noise, run more smoothly, more efficient;The open door operation and safety interlock device, to ensure open the door safe and convenient;Linkage type pressure screen, make the screen surface replacement more convenient and reliable ;Application of new material such as tungsten carbide, extend the hammer crushing service life of wearing parts;The standard Siemens (bei) motor and the import bearings (SKF/NSK international first-line brand) Production: raw materials with corn, moisture 14% or less
Advantages:
u Adopt tear circle type grinding chamber, effectively eliminate circumfluence phenomenon in the process of grinding, increase production;
u The U-shape second time grinding structure is installed at the bottom of grinding chamber increase the beating times to get more uniform grinding grain size;
u Both coarse and fine grinding can be realized by adjusting the clearance between hammer and screen mesh, thus one machine can be used as two;
u The key spare parts adopts originally imported to ensure longer service life and lower maintenance cost;
u Fully opened operating door, convenient maintenance and easy to replace hammer;
u Compared with 128 series hammer mill, it has smaller capacity.
Technical parameters
Model | Overall dimension(mm) | Main shaft speed(rpm) | Power(kw) | Capacity (t/h) |
SFSP563-45 | 1700*890*1200 | 2950 | 37/45 | 1.3-2.8/ 4.0-7.5 |
SFSP63-35 | 1510*890*1200 | 2950 | 22/30 | 1.0-1.8/ 1.0-5.0
|
