9HWP (Q) Series Horizontal Ribbon Mixer Machine

9HWP (Q) Series Horizontal Ribbon Mixer Machine photo-1
9HWP (Q) Series Horizontal Ribbon Mixer Machine photo-2
9HWP (Q) Series Horizontal Ribbon Mixer Machine photo-3
9HWP (Q) Series Horizontal Ribbon Mixer Machine photo-4
9HWP (Q) Series Horizontal Ribbon Mixer Machine photo-5
9HWP (Q) Series Horizontal Ribbon Mixer Machine photo-6
US$ 100 - 680 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
HEXIE
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name HEXIE
Model Number 9HWP
Type Other, Horizontal Ribbon Mixer Machine
Voltage 220V/380V
Power(W) 22kw
Dimension(L*W*H) 2200*1000*1500mm
Weight 120 kg
Certification ISO9001
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

9HWP (Q) Series Horizontal Ribbon Mixer Machine

Product Description

 Applied range

9HWP Series Horizontal Ribbon Mixer is mainly used to coating, dry powder and chemical industry Used to mix various dry powder material metered in proportion. Also can be used to mixing feed and cooperate with other feed processing equipment in medium and small sized farm.

Product features

Applicable to the feed, food, chemical, pharmaceutical, pesticide and other industries in powder, granular, flake and miscellaneous materials mixing; Horizontal, batch type mixer, each batch mixing time is 3 ~ 6 minutes, especially for mixing the feed which need add the much liquid ; Inside the machine equipped with grease adding pipe and return air pipe, open structure, low residual, discharge rapidly, the overall structure is reasonable, convenient operation and maintenance; With creative generation ribbon blade rotor structure, no mixed corner, cv ≤ 5% , Shaft end and discharging door adopt unique mature sealing technology, ensure no leakage. With the standard GB motor, domestic gear speed reducer, reducer motor dose belt driveapply to need quick exhaust situation.

Advantages

1. With simple and reasonable structure, easy to maintenance, safe and reliable, high mixing evenness, short mixing time;

2. Bottom with enlarged door, which greatly reduce the residual;

3. Can be used as compound feed unit for medium and small sized farm, to mix various dry powders metered in proportion.

Technical parameters

Model

 Volume(m ³)

Mixing time(min)

Mixing evenness CV (%)

Power

(kw)

9HWP-500Q

1.0

3-5

5

7.5

9HWP-1000Q

 2.0

3-5

≤5

15
