1.2-3 Screen Mesh 150kg/h Barley Corn Straw Hammer Mill

Xinxiang Xingtian Machinery Manufacturing Co., Ltd.
1.2-3 Screen Mesh 150kg/h Barley Corn Straw Hammer Mill thumbnail-1
1.2-3 Screen Mesh 150kg/h Barley Corn Straw Hammer Mill thumbnail-2
1.2-3 Screen Mesh 150kg/h Barley Corn Straw Hammer Mill thumbnail-3
1.2-3 Screen Mesh 150kg/h Barley Corn Straw Hammer Mill thumbnail-4
1.2-3 Screen Mesh 150kg/h Barley Corn Straw Hammer Mill thumbnail-5
1.2-3 Screen Mesh 150kg/h Barley Corn Straw Hammer Mill photo-1
1.2-3 Screen Mesh 150kg/h Barley Corn Straw Hammer Mill photo-2
1.2-3 Screen Mesh 150kg/h Barley Corn Straw Hammer Mill photo-3
1.2-3 Screen Mesh 150kg/h Barley Corn Straw Hammer Mill photo-4
1.2-3 Screen Mesh 150kg/h Barley Corn Straw Hammer Mill photo-5
US$ 1 - 999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
XT Machinery
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Henan, China
Brand Name XT Machinery
Model Number 9FQ40
Type Mill Machine
Voltage 380V 50HZ 3phase
Power(W) 22kw
Dimension(L*W*H) 1100*930*1030mm
Weight 275 kg
Certification ISO9001
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

1.2-3 screen mesh 150kg/h barley corn straw hammer mill

1.2-3 screen mesh 150kg/h barley corn straw hammer mill

Description

9FQ Series hammermill is used in the pelleting process to take materials which are many different sizes and turns them into smaller more consistent size particles.



In 1.2-3 screen mesh 150kg/h barley corn straw hammer mill, hammers strike the material over and over until it is small enough to fit through a screen. A large amount of air is also moving through the hammermill and it drags the material small enough to make it through the holes in the screen away to the next process.



1.2-3 screen mesh 150kg/h barley corn straw hammer mill

Features



1.Compact design with high production efficiency, easy operation and maintenance;

2.Quenched manganese steel hammers with hardness HRC56-62 ,shows excellent wear-resistance;

3.Upper and lower housing made from cast iron or carbon steel for long service life;

4.Different mesh screens available

5.Electric motor or engine powered







1.2-3 screen mesh 150kg/h barley corn straw hammer mill



                                                                                    casted Upper and lower hammer mill housing



Application

1.2-3 screen mesh 150kg/h barley corn straw hammer mill is widely uesd in livestock farm, feed processing plant, Ethanol plant and many industries to grind:



1. Roughages

     stalks of rice, wheat, corn, sorghum, oat and bean

     vine and stem of tuber crops

     corn cobs

     husks and shells

     hay



2. Concentrates such as corn/maize, wheat and most kernels



3.Others:

   Coal
   Biomass & Biofuels
   Crab, Clam & Oyster Shells
   Salt Cake

   Waste papers  and more...



Why PTO hammer mill?



A power take-off (PTO) is any of several methods for taking power from a power source, such as a running engine, and transmitting it to an application such as an attached implement or separate machines.



Voltage in countries differ from one another, or not accessible for some regions. 1.2-3 screen mesh 150kg/h barley corn straw hammer mill can be driven by a electric motor or an engine for your choice.





Particle Size Refference

1.2-3 screen mesh 150kg/h barley corn straw hammer mill

1.2-3 screen mesh 150kg/h barley corn straw hammer mill

Parameter



Model

Weight

(KG)

Dimension

(MM)

Match Power

Hammer

Qty

Screen Mesh

(MM)

(KW)

(HP)

9FQ36

85

900*750*1070

5.5-7.5

8-10

12

0.5-5

9FQ40

160

945*835*768

7.5-11

10-15

12

1.2-8

9FQ42

125

730*650*920

11-15

15-20

16

1.2-20

9FQ50

280

1150*1200*1090

11-15

15-20

16

1.2-20

9FQ50-40

275

1100*930*1030

22-37

     30-50

24

1.2-30

9FQ50-60

380

1157*1355*1030

37-45

 50-60

36

1.2-30



Output



Model

Output (kg/h)

Corn kernel

Corn Straw

Peanut shell

Bean Stalk

9FQ36

500-600

80-150

300-350

130-230

9FQ40

800-1000

80-150

300-350

130-230

9FQ42

800-1000

100-200

400-500

200-250

9FQ50

1000-1200

150-250

500-600

200-300

9FQ50-40

2000-2500

370-440

900-1100

460-550

9FQ50-60

2500-3000

800-1200

1100-1500

900-1125



Above output refers to water content of materials less than 14% with 2mm screen mesh



Output may vary with screen mesh



Package

 1.2-3 screen mesh 150kg/h barley corn straw hammer mill
