22kw or 30hp 2000kg per hour corn hammer mill for sale
- 300 Set / Sets per Month
- Qingdao
- T/T
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | XT Machinery |
Model Number: | 9FQ-50-40 | Type: | Mill Machine | Voltage: | 380V 50HZ 3phase |
Power(W): | 22kw | Dimension(L*W*H): | 1100*930*1030mm | Weight: | 275 kg |
Certification: | ISO9001 | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
22kw or 30hp 2000kg per hour corn hammer mill for sale
Description
22kw or 30hp 2000kg per hour corn hammer mill is primarily used to crush material into smaller pieces. In the farming industry, hammer mills are used to grind down the harvested crops into a flour-like substance, which is then stored or fed to livestock.
Hammer Mills come in variety of sizes for different industries, but are primarily used in the farming industry. For your convenience, we offer four different models of Hammer Mill so we can meet all your harvesting needs.
Features
1.Compact design with high production efficiency, easy operation and maintenance;
2.Quenched manganese steel hammers with hardness HRC56-62 ,shows excellent wear-resistance;
3.Upper and lower housing made from cast iron or carbon steel for long service life;
4.Different mesh screens available
5.Electric motor or engine powered
casted Upper and lower hammer mill housing
Application
22kw or 30hp 2000kg per hour corn hammer mill is widely uesd in livestock farm, feed processing plant, Ethanol plant and many industries to grind:
1. Roughages
stalks of rice, wheat, corn, sorghum, oat and bean
vine and stem of tuber crops
corn cobs
husks and shells
hay
2. Concentrates such as corn/maize, wheat and most kernels
3.Others:
Coal
Biomass & Biofuels
Crab, Clam & Oyster Shells
Salt Cake
Waste papers and more...
Why PTO hammer mill?
A power take-off (PTO) is any of several methods for taking power from a power source, such as a running engine, and transmitting it to an application such as an attached implement or separate machines.
Voltage in countries differ from one another, or not accessible for some regions. 22kw or 30hp 2000kg per hour corn hammer mill can be driven by a electric motor or an engine for your choice.
Particle Size Refference
Parameter
Model | Weight (KG) | Dimension (MM) | Match Power | Hammer Qty | Screen Mesh (MM) | |
(KW) | (HP) | |||||
9FQ36 | 85 | 900*750*1070 | 5.5-7.5 | 8-10 | 12 | 0.5-5 |
9FQ40 | 160 | 945*835*768 | 7.5-11 | 10-15 | 12 | 1.2-8 |
9FQ42 | 125 | 730*650*920 | 11-15 | 15-20 | 16 | 1.2-20 |
9FQ50 | 280 | 1150*1200*1090 | 11-15 | 15-20 | 16 | 1.2-20 |
9FQ50-40 | 275 | 1100*930*1030 | 22-37 | 30-50 | 24 | 1.2-30 |
9FQ50-60 | 380 | 1157*1355*1030 | 37-45 | 50-60 | 36 | 1.2-30 |
Output
Model | Output (kg/h) | |||
Corn kernel | Corn Straw | Peanut shell | Bean Stalk | |
9FQ36 | 500-600 | 80-150 | 300-350 | 130-230 |
9FQ40 | 800-1000 | 80-150 | 300-350 | 130-230 |
9FQ42 | 800-1000 | 100-200 | 400-500 | 200-250 |
9FQ50 | 1000-1200 | 150-250 | 500-600 | 200-300 |
9FQ50-40 | 2000-2500 | 370-440 | 900-1100 | 460-550 |
9FQ50-60 | 2500-3000 | 800-1200 | 1100-1500 | 900-1125 |
Above output refers to water content of materials less than 14% with 2mm screen mesh
Output may vary with screen mesh
Package
More Product
Click here see 9FQ-36 series Hammer Mill
Click here see 9FQ-40 series Hammer Mill
Click here see 9FQ-42 series Hammer Mill
Click here see 9FQ-50 series Hammer Mill
