Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines

Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines thumbnail-1
Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines thumbnail-2
Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines thumbnail-3
Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines thumbnail-4
Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines thumbnail-5
Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines thumbnail-6
Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines photo-1
Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines photo-2
Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines photo-3
Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines photo-4
Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines photo-5
Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines photo-6
US$ 10,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
UNGAR
Contact Supplier Request Quote Chat Now
Ungar Machinery (Shanghai) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name UNGAR
Model Number UNST-6010
Dimension(L*W*H) 110T 3200*179*1400mm
Certification EC ISO SGS
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas

Ungar Aluminum Container Automatic Stacker

(UNST-6010) 4-Lines







Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines





Advantages:
1. Desing for labor saving and production efficiency.
2. Stack trays and containers of different dimensions.
3. Easy to operate and adjust based on customize requirements.

Ungar Productive Aluminum Foil Container Machine Automatic Stacker Multi Cavities Mould Collecting Machine (UNST-6010) 4-Lines



 Auto container stacker
 Model:The UNST-6010 is for 55Ton/63Ton/80Ton/110Ton,with 1 to 5 lanes
 Collector belt width 600mm(45ton)/850mm(63ton)/1080mm(80ton)/1340mm(110ton)
 Collector belt heihgt 1100+-100mm (According press machine's size, we will adjustable height system on requested)
 Min. container dimensions 80 x 120mm(Smaller on request)
 Container dimensions 230 x 340mm(4-Lines)
The lanes could be less or more on your condition, also depend on container shape.
 Max. height of container stack 300mm(Depend on the container shape and size)
 Lifting system By step motor and linear guide
 Photocell electronic counting device Container counter automatically stops press at top of stroke in emergency situations.
 Control panel Touch screen panel
 Stacking system Photo electric sensor controls the height of the stack with electric brake system.
 Installed Power 1Kw
 Air consumption(2lanes) 0.1m3/Min
 Net.weight 300kg
 Stacker dimensions(L*W*H) 3200x1790x1400mm
 Notice:The Stackers specifications depend on container size and shape and the mould cavities.
