The advantages of finished pellets:
1.as biomass fuels :(Dia4-10mm,or bigger)
Without dust ,smokeless, Cleanliness.no CO, pollution-free.
High density and heat value, easy burn ,low cost ,convenient use.
2.for animal feed :(dia 2.5 -6mm,or bigger)Taste good ,high-usage
Usage of the machine:
It is used to produce pellet feed for pig, cattle, sheep, rabbit, chicken, duck, fish,etc; or To make inorganic fertilizer granule;this pellet machine also used to produce the wood pellet for fuel.
The requirement of raw material:
The raw material of this pellet machine usually below 6mm powder, if your raw material is straw, wood branch , corn husk and so on, you should grind them into powder at first, and then you can directly use the machine.
Products description:
1. Pellet press can make all kinds of bio-mass material to be solid pellets which is for burning fuel or animal feed.
2. We have new improved models for wood pellet making. Specially design and improved machines according to European standard, with closed house to cover motor, CE electrical parts & isolated protective plate for the electrical panel.
3. Our pellet mill also can process all kinds of sawdust. Paddy Straw, Sunflower Stalk, Forestry Wastes, Wood Chips, Chemical And Many Other Wastes Or Solid Powder Material.
4. Our pellet mill have CE certificate, Which all parts can meet EU standard.
Some type pellet machine and the parts of pellet machine
The technology parameters of small bio wood pellet machine:
APPEARANCE |
DRIVEN BY |
MODEL |
POWER |
CAPACITY (kg/h) |
WEIGHT (nw/gw) |
PACKING SIZE (mm) |
|
Electric motor |
ZLSP-D 150B |
5.5kW |
50-100 |
95/110 |
800x450x700 |
ZLSP-D 200B |
7.5 kW |
80-120 |
200/230 |
1050x480x930 |
||
ZLSP-D 230B |
11 kW |
120-200 |
290/320 |
1180x540x1000 |
||
ZLSP-D 260B |
15 kW |
160-250 |
320/360 |
1240x540x950 |
||
ZLSP-D 300B |
22 kW |
250-400 |
350/380 |
1300x560x1100 |
||
|
Electric motor |
ZLSP-D 150C |
5.5kW |
60-110 |
105/125 |
1000x480x780 |
ZLSP-D 200C |
7.5 kW |
80-120 |
210x230 |
1050x550x830 |
||
ZLSP-D 230C |
11 kW |
120-200 |
290/320 |
1200x560x950 |
||
ZLSP-D 260C |
15 kW |
160-250 |
340/370 |
1240x560x1000 |
||
ZLSP-D 300C |
22 kW |
250-400 |
425/465 |
1300X620X1100 |
||
|
Diesel engine |
ZLSP-D 150A |
8HP |
50-100 |
180/220 |
100x500x750 |
ZLSP-D 200A |
15 HP |
80-120 |
210/240 |
1460x750x900 |
||
ZLSP-D 230A |
22 HP |
120-200 |
280/310 |
1560x850x1100 |
||
ZLSP-D 260A |
30 HP |
160-250 |
330/360 |
1200x500x1070 |
||
ZLSP-D 300A |
41 HP |
250-400 |
410-450 |
1220x600x1000 |
||
|
Gasoline engine |
ZLSP-150Q
|
7.5HP |
90-120 |
180-220 |
1000x500x750 |
|
PTO |
ZLSP-D 150P |
≥8 HP |
50-100 |
90-110 |
900x540x1020 |
ZLSP-D 200P |
≥15 HP |
80-120 |
130/150 |
1000x540x1020 |
||
ZLSP-D 230P |
≥22 HP |
120-200 |
175/200 |
1000x540x1020 |
||
ZLSP-D 260P |
≥33 HP |
160-250 |
235/255 |
1050x540x900 |
||
ZLSP-D 300P |
≥41 HP |
250-400 |
305/325 |
1100x540x1000 |
Henan Donging Heavy Industry Equipment CO.,LTD is a new energy equipment, high humidity material drying equipment, environmental protection and research-based professional development of enterprise groups, is the only domestic industry drying equipment research and development, design, production and sales of high-tech enterprise group, and the first certified by ISO quality management system. Dongding Heavy Industry Equipment is a project co-drying equipment, Tsinghua University, Henan University research base, China Petroleum and Chemical Industry Federation drying technology professional group member units, Henan Province, the top ten most of the growth of science and technology enterprises.
As a professional manufacture,we are supply Vacuum dryer,rotary dryer, wood pellet machine, biomass pellet machine, coal gasifier,sawdust burner,wood/biomass pellet burner, wood/biomass prowder burner,biomass gasifier,wood chipper,wood hammer mill and other machine.
Export standard container 20GP OR 40GP,40HQ,FR container,In bulk,the spare parts in wooden case.
About the machine:
Q1. Does this machine can make wood pellets?
Answer: This machine can make both wood pellets and feed pellets. When making feed pellets, it performs better and the capacity is bigger.
Q2. What are the spare parts for this series pellet machine?
Answer: The spare parts for this machine are one die and two rollers.
Q3. How often should I change the spare parts?
Answer: The long life time of the die and rollers is 1500 hours at least. It needs to change the easy wear parts every five months. If maintained and used well, the parts can be used about EIGHT months or more.
Q4. How often would the machine need to be serviced?
Answer: Every three months is the best for the machine.
Q5. Does the raw materials require any additives to aid in the forming of the pellets?
Answers: It doesn't need to add any additives to aid in the forming of pellets. The only thing you need to do is to control the moisture of the raw materials properly.
