100-200 Kg/hour High Quality Wood Pellet Machine/Wood Pellet Making Machine With Low Cost

100-200 Kg/hour High Quality Wood Pellet Machine/Wood Pellet Making Machine With Low Cost thumbnail-1
100-200 Kg/hour High Quality Wood Pellet Machine/Wood Pellet Making Machine With Low Cost thumbnail-2
100-200 Kg/hour High Quality Wood Pellet Machine/Wood Pellet Making Machine With Low Cost thumbnail-3
100-200 Kg/hour High Quality Wood Pellet Machine/Wood Pellet Making Machine With Low Cost thumbnail-4
100-200 Kg/hour High Quality Wood Pellet Machine/Wood Pellet Making Machine With Low Cost photo-1
100-200 Kg/hour High Quality Wood Pellet Machine/Wood Pellet Making Machine With Low Cost photo-2
100-200 Kg/hour High Quality Wood Pellet Machine/Wood Pellet Making Machine With Low Cost photo-3
100-200 Kg/hour High Quality Wood Pellet Machine/Wood Pellet Making Machine With Low Cost photo-4
US$ 1,000 - 1,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
Dongding Heavy Industry
Contact Supplier Request Quote Chat Now
Henan Dongding Heavy Industry Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Henan, China
Brand Name Dongding Heavy Industry
Model Number ZLSP-M 260C pellet machine
Voltage 380V/220V
Power(W) 15 kw
Dimension(L*W*H) different model wood pellet machine
Weight 370kg
Certification CE ISO
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Product feature:Flat-die Pellet mill is easy to operate, the die clearance can be changed,

to make different size pellet.



Application:Flat-die pellet machine is used for making fuel pellet,use in school,power plant,

hospital and also can make feed pellet with high efficiency,and multi-functional.



Product introduction:Flat-die Pellet Machine is used for making fuel pellet,use in school,power plant,hospital and also can

 make feed pellet with high efficiency,for chicken,cow,duck,sheep and so on. It also can be used to

 make fertilizer pellet ,multi-functional. The main raw material is widely,such as sawdust,rice husk,

cotton stalk,and so on....



Flat-die pellet machine have two parts,one is drive part (include motor,,gear case),

another part is pelletize part(bearing,mould, roller,knife).



The working principle:Flat-die pellet machine is easy to operate, just put the raw material into the machine from

 feed port,the mould rotate friction,the roller rotate,by these two power, the raw material was pressed

 into mould,and be the cylindrical, these pellet will be sent out through the discharge port, in the

 discharge port, there is knifes, when the pellet go though, the knife will rotate and cut the pellet into

 small part, according to customer’s demand, the die clearance can be changed to achieved to get

different size pellet.



Advantage:Flat-die pellet machine’s advantage:1.the drive part install the automatic filtration cycle

and lubrication system, to make sure the gear and large bearings can lubrication constantly.



1.The pellet room have the automatic batch-type oil supply system,lubrication system,

to ensure the lubrication between roller and large bearings.



2.Tapered roller can induce the friction which is not necessary.



3.Out flat-die ;pellet machine set a observation door, you can observe the machine’s working ,

and check the machine at any time, also it’s convenient to maintain.



4.There is a fan with machine’s gear, can ensure the machine radiating timely.



5.The flat-die pellet machine is easy to operate,and different kinds of type, suitable for home use,

farmer,and any other industry..



 The different model and parts of wood pellet machine



100-200 kg/hour high Quality Wood Pellet Machine/Wood Pellet Making Machine with low cost

The technology parameters of small bio wood pellet machine:

APPEARANCE

DRIVEN BY

MODEL

POWER

CAPACITY (kg/h)

WEIGHT (nw/gw)

PACKING SIZE (mm)

 100-200 kg/hour high Quality Wood Pellet Machine/Wood Pellet Making Machine with low cost

Electric motor

ZLSP-D 150B

5.5kW

50-100

95/110

800x450x700

ZLSP-D 200B

7.5 kW

80-120

200/230

1050x480x930

ZLSP-D 230B

11 kW

120-200

290/320

1180x540x1000

ZLSP-D 260B

15 kW

160-250

320/360

1240x540x950

ZLSP-D 300B

22 kW

250-400

350/380

1300x560x1100

 100-200 kg/hour high Quality Wood Pellet Machine/Wood Pellet Making Machine with low cost

Electric motor
with enclosure

ZLSP-D 150C

5.5kW

60-110

105/125

1000x480x780

ZLSP-D 200C

7.5 kW

80-120

210x230

1050x550x830

ZLSP-D 230C

11 kW

120-200

290/320

1200x560x950

ZLSP-D 260C

15 kW

160-250

340/370

1240x560x1000

ZLSP-D 300C

22 kW

250-400

425/465

1300X620X1100

 100-200 kg/hour high Quality Wood Pellet Machine/Wood Pellet Making Machine with low cost

Diesel engine

ZLSP-D 150A

8HP

50-100

180/220

100x500x750

ZLSP-D 200A

15 HP

80-120

210/240

1460x750x900

ZLSP-D 230A

22 HP

120-200

280/310

1560x850x1100

ZLSP-D 260A

30 HP

160-250

330/360

1200x500x1070

ZLSP-D 300A

41 HP

250-400

410-450

1220x600x1000

  100-200 kg/hour high Quality Wood Pellet Machine/Wood Pellet Making Machine with low cost

Gasoline engine

ZLSP-150Q



















7.5HP

90-120

180-220

1000x500x750

 100-200 kg/hour high Quality Wood Pellet Machine/Wood Pellet Making Machine with low cost

PTO

ZLSP-D 150P

≥8 HP

50-100

90-110

900x540x1020

ZLSP-D 200P

≥15 HP

80-120

130/150

1000x540x1020

ZLSP-D 230P

≥22 HP

120-200

175/200

1000x540x1020

ZLSP-D 260P

≥33 HP

160-250

235/255

1050x540x900

ZLSP-D 300P

≥41 HP

250-400

305/325

1100x540x1000



Company Information

 Henan Donging Heavy Industry Equipment CO.,LTD  is a new energy equipment, high humidity material drying equipment, environmental protection and research-based professional development of enterprise groups, is the only domestic industry drying equipment research and development, design, production and sales of high-tech enterprise group, and the first certified by ISO quality management system. Dongding Heavy Industry Equipment is a project co-drying equipment, Tsinghua University, Henan University research base, China Petroleum and Chemical Industry Federation drying technology professional group member units, Henan Province, the top ten most of the growth of science and technology enterprises.



As a professional manufacture,we are supply Vacuum dryer,rotary dryer, wood pellet machine, biomass pellet machine, coal gasifier,sawdust burner,wood/biomass pellet burner, wood/biomass prowder burner,biomass gasifier,wood chipper,wood hammer mill and other machine.

 100-200 kg/hour high Quality Wood Pellet Machine/Wood Pellet Making Machine with low cost

100-200 kg/hour high Quality Wood Pellet Machine/Wood Pellet Making Machine with low cost





Packaging & Shipping

  Export standard container 20GP OR 40GP,40HQ,FR container,In bulk,the spare parts in wooden case.

100-200 kg/hour high Quality Wood Pellet Machine/Wood Pellet Making Machine with low cost100-200 kg/hour high Quality Wood Pellet Machine/Wood Pellet Making Machine with low cost

100-200 kg/hour high Quality Wood Pellet Machine/Wood Pellet Making Machine with low cost



FAQ

 About the machine:


Q1. Does this machine can make wood pellets?
Answer: This machine can make both wood pellets and feed pellets. When making feed pellets, it performs better and the capacity is bigger.

Q2. What are the spare parts for this series pellet machine?
Answer: The spare parts for this machine are one die and two rollers.

Q3. How often should I change the spare parts?
Answer: The long life time of the die and rollers is 1500 hours at least. It needs to change the easy wear parts every five months. If maintained and used well, the parts can be used about EIGHT months or more.

Q4. How often would the machine need to be serviced?
Answer: Every three months is the best for the machine.

Q5. Does the raw materials require any additives to aid in the forming of the pellets?
Answers: It doesn't need to add any additives to aid in the forming of pellets. The only thing you need to do is to control the moisture of the raw materials properly.
