Wood pellet machine / wood pellet mill in Malaysia
Tel:+8613001730022 Skype:pelletmachine17 wechat: rotexmaster0022
Vertical Ring Die Pellet Machine is a new biomass fule production machinery by using crushed
sawdust and bran from eucalyptus,pine,birch,poplar,fruit and agricultural straw, bamboo.
Compared with the old machine,this new vertical ring die pellet machine efficiently.
This product is mainly applicable for difficult molding materials with low adhesion rate, for example
rice husk, sunflower husk, peanut shell and fruit shell; branch, stem, rind and other wood waste; a
variety of crop stalks; rubber, cement, ash and other chemical materials. It can be used in feed mill, wood processing plants, fuel plants, fertilizer plants, chemical plants etc.
YGKJ series efficient vertical ring die pellet machine is an ideal dense compression molding
equipment.
Advantages of choose us:
(1) vertical feeding
(2) roller rotate,Centrifugal force role ,material distribute uniformly
(3) two layer roller,saving cost ,good effect.
(4) ring die,vertical structure, help pellet room temperature reducing
(5) Separate discharging structure, improve the pellet forming rate
(6) with good lubricate device, protect the machine bearing
(7) feeding device with frequency conversion
Technical Parameters:
Model | Power (Kw) | Pellet Specification (mm) | Ring die inner diameter (mm) | Output (t/h) | Measurement (mm) | Weight (t) |
YGKJ-550 | 75 | φ4-φ12 | 550 | 0.7-1.2 | 2300×1000×1780 | 4.8 |
YGKJ-560 | 90 | φ4-φ12 | 560 | 1-1.5 | 2600×1300×2300 | 5.8 |
YGKJ-580 | 160 | φ4-φ12 | 580 | 1.5-2 | 2900×1300×2400 | 6.5 |
YGKJ-850 | 220 | φ4-φ12 | 850 | 2-3 | 3750×1650×3250 | 12.6 |
After-sales Service:
We abide by the principle of service first,quality first,brand first,reputation first,supply the best, professional service to solve your problem. Look forward to win-win cooperation with you .
Picture show:
How did you define your model as 560/680/850?
Rotex Master:The YGKJ series 560/680/850 is defined according to the main parts model's size. For example, 560, the mold's diameter is 560mm.
What's the suitable moisture of material that to be granulated?
Rotex Master:The moisture should be controlled under 20%
How long is your guarantee?
Rotex Master: One Year guarantee. We shall supply free exchange for spare parts. After this period, we shall charge at low cost to keep after service. You will be welcome to contact us with any problem might occurred.
Company information:
The company's products through the ISO international quality system certification .
Shandong Rotex Machinery.,Co.Ltd, Which located in Jinan , Capital of Shandong
Province.
Our Company has ISO9001_2000 Certification,CE Certification,SGS Certification etc.
Products cover the enviromental carbon, biomass,urban and rural environment,
culture and other fields.There are five main series: the biomass compression
molding
equipment, garbage disposal equipment for urban and rural ,organic fertilizer
equipment and environment, Feeder Equipment and Environmental protection
equipment .
Companies adhere to the “Service, Quality First, Brand, Reputation First” Principle
to provide our customers with the best quality services .Welcome the customers to visit to our
factory.
If you are intrerested in our production please contact me :
Thanks for reading my products information. If you have any questions, please
don’t hesitate to contact me, and then I will provide you the best and professional service!
