CE Approved Rotary Screener/sawdust Sieving Machine Before Making Wood Pellet

CE Approved Rotary Screener/sawdust Sieving Machine Before Making Wood Pellet photo-1
CE Approved Rotary Screener/sawdust Sieving Machine Before Making Wood Pellet photo-2
CE Approved Rotary Screener/sawdust Sieving Machine Before Making Wood Pellet photo-3
CE Approved Rotary Screener/sawdust Sieving Machine Before Making Wood Pellet photo-4
CE Approved Rotary Screener/sawdust Sieving Machine Before Making Wood Pellet photo-5
US$ 1,890 - 2,200 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
ROTEXMASTER
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name ROTEXMASTER
Model Number YGTS80x1.5
After-sales Service Provided Engineers available to service machinery overseas

CE approved rotary screener/sawdust sieving machine before making wood pellet



Product Description

♥ Rotary screener machine mainly makes up with motor,reducer,roller device,frame,sealing cover,inlet and outlet.

♥The roller device is titled on the frame.The motor is connected with roller device through

shaft coupling by the reducer,and drive roller device around its axis of rotation.

♥When the materials fed in the roller device,due to tilt and rotation of roller device,the

material on the screen surface roll and rotate.

♥Finally the qualified materials will be discharged through the discharge port at the bottom

of roller,the unqualified materials will be diacharged through the discharge port at the end

of the roller device.

♥Due to the material flip and scroll,the material stuck in screener will be pop

up,to prevent the mesh plug.



 CE approved rotary screener/sawdust sieving machine before making wood pellet

CE approved rotary screener/sawdust sieving machine before making wood pellet



Data of biomass saw dust screener in our company

Model

Capacity(t/h)

Dimension(mm)

Power(kw)

YGTS80x2

0.5-1

 2150*1200*1200

1.1

YGTS100x2

1-2

  2800*1300*1460

1.5

YGTS130x3

1.5-4

  4420*1500*3800

2.2

YGTS150x4

3-5

  5160*1700*4400

3

YGTS180x6

5-10

   6300*2200*2600

4

YGYS200x6

8-12

   7000*2500*5000

5.5





Features of Rotary Screener machine



1.It is suitable to separate various materials included poor quality of coal, coal slime,

or soot.

2.It has higher efficiency by the installation of comb shape screen structure.

3.It do not require special facility and suitable for various material feeding methods.

4.Cylindrical shape of screen provided larger surface area which has higher possibility

of materials to contact with the screen mesh; therefore, it has higher capacity and more

effective.

5.It is a energy saving equipment.It is durable and low maintenance cost.

6.The equipment is fully sealed with a cover to minimize the suspension of fine material

in the air during the operation, able to avoid working environment pollution.

7.Since it is covered, less noise pollution during the operation.

8.The checking and the maintenance are easily to process through opening on the cover.





Company Information



 Shandong ROTEX  Machinery Co.,Ltd  is the professional manufacturer of pellet machine in China.
Our main products includes: three series of flat dies, ring dies and roller pellet mills and briquetting
presses, wood pellet mills, feed pellet mills, organic fertilizer pellet mills, bio  energy pellet mills,
dryers, coolers, hammer mills, mixers, wood chippers and complete lines.This unit the strong technical
force, advanced production technology, perfect after-sales service.




 CE approved rotary screener/sawdust sieving machine before making wood pelletCE approved rotary screener/sawdust sieving machine before making wood pellet
