Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

Stainless Steel Sausage Clipper Machine/Sausage Linking Machine photo-1
Stainless Steel Sausage Clipper Machine/Sausage Linking Machine photo-2
US$ 318 - 6,030 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
WELLY
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai/Ningbo/Tianjin/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name WELLY
Model Number WYQD-2
Production Capacity 300~500kg/h
Voltage 220V/380V
Power(W) 1.5kw
Weight 200kg
Dimension(L*W*H) 650*640*1500mm
Certification CE ISO
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

We have two types sausage clipper machine: pneumatic quantity type, hydraulic pressure type sausage clipper machine.

1. High quality stainless steel materials.

2. Good performance, stable running.

3. Reach health standard sausage clipper machine

Stainless Steel Sausage Clipper Machine/Sausage Linking Machine.Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

Product Description

I. Pneumatic quantitation type sausage clipper machine

i. Technical Parameters of sausage clipper machine

Model

WYQD-2

Twist time

60 time/min

Power

1.5kw

Barrel volume

57L

Quantity filling range

30~1000g(adjustable)

capacity

300~500kg/h

Function

Quantity filling,

automatic twist(kink)

Filling tube size

φ16,φ18,φ20,

φ22,φ25mm

ii. Brief description of sausage clipper machine

1. This pneumatic quantitation type sausage clipper machine is suitable for filling various of sausage, ham, and can products, it’s widely used in meat process industry, sausage process industry. The quantity filling is accuracy, the error is less than 3g.

2. This pneumatic quantitation sausage clipper machine is with automatic quantitative filling and twisting function.
3. This pneumatic quantitation type sausage clipper machine is suitable for filling various kinds of sausage and mash products.
4. This pneumatic quantitation type sausage clipper machine is with high degree automation, advanced technology, stable running, simple operation, easy cleaning, and high efficiency; it’s with characteristics of guarantee the quality, retain freshness, and will not damage the materials’s ingredients.
5. This pneumatic quantitation type sausage clipper machine is a new advanced equpment, it uses air cylinder to drive piston to filling and absorbing the stuffings into sausage.

Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

II. Hydraulic Type sausage clipper machine

i. Technical Parameters of sausage clipper machine

Model

Power

Barrel volume

Capacity

Filling diameter

Machine size

Machine weight

WYGC-30

1.5kw

30L

300~500kg/h

12-45mm

1050*670*1680mm

250kg

WYGC-50

50L1.5kw

50L

500~800kg/h

12-45mm

1150*700*1760mm

280kg

ii. Brief description of sausage clipper machine

1. This hydraulic type sausage clipper machine is the necessary equipment for process sausage product. It can fill big, medium, and small size sausage, it’s suitable for filling animal casing, collagen casing, and plastic casing. It’s specially have good filling effect in drier stuffing materials than other kind sausage machine.
2. This hydraulic type sausage clipper machine is designed with hopper and dish valve, so it can realize to filling sausage continuously without opening the cover, improve the working efficiency.
3. This hydraulic type sausage clipper machine adopts piston type hydraulic drive, the stuffing materials in barrel will be pushed out under the function of hydraulic cylinder after calibrating the working pressure.

Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

Packaging & Shipping

 i. Packaging of sausage clipper machine

Our sausage clipper machine will be packaged by standard export wooden package case, it can ensure the machine intact.

 Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

ii. Shipping of sausage clipper machine

1. We can deliver the sausage clipper machine to your nearest seaport or airport, or door to door to you by express, etc.
2. Any special requirement of shipping, please talk with us, we will help you to solve the problems.

Stainless Steel Sausage Clipper Machine/Sausage Linking Machine

FAQ

1. Q: This is my first time to import, how can I get the machine?

A: After you confirm the machine to order and pay, we can help you to deliver the machine to your nearest seaport or airport, or door to door to you by express, etc., We are very experienced, please rest assured.
2. Q: This is my first time to use this machine, is it easy to operate?
A: This sausage clipper machine is very easy to operate, it only need one people to operate. And after deliver the machine, we will also provide you the English user manual and simple video for your reference.
3. Q: How is the quality of the machine?
A: Our sausage clipper machine adopts 304 stainless steel materials, with reasonable design,  and careful produce, etc., before deliver the machine, we will test the machine, after ensure the machine's good running and performance, then we will deliver it, please don’t worry.

4Q: What’s the payment method?
A: We accept most of the payment method, such as, T/T, Western Union, Paypal, L/C, etc.
5. Q: Why choose us?
A:  We can provide the machine with good quality and best price, also good and professional sale and after-sale service, if the machine has any problems in the future, we will provide the technical help and spare parts according to your need.

Company Information

Henan Welly Machinery Equipment Co., Ltd. is a comprehensive enterprise which is professional in research, manufacture, and sales. we are specialized in more than 50 food processing machinery equipment, such as: egg processing machinery, meat processing machinery, fish processing machinery, sausage processing machinery, snack food processing machinery, fryer machine, fried potato chips and french fries processing equipment, fruit and vegetable cleaning, peeling, and cutting machinery, vegetable and food blanching machinery, nuts processing machinery, etc., we have more than 10 years experiences in the field, we have export the machines to more than 100 countries, such as, USA, Canada, Astralia, UK, Singapore, Thailand, Indonesia, Saudi Arabia, UAE, Dubai, etc., and get very good feedbacks by our clients.
Henan Welly Machinery Equipment Co., Ltd. could arrange production according to the customized requirements of customers as its pre-process and workshop layout design for the users. Besides, as the tenet of our company is quality and service, clients comes first, since our new products are sold, they are quickly recognized by new and old customers all over the world!

We have a 600 m² showroom in our factory, you are very welcome to visit us!
