1.Automatic chocolate nut coating machine introduction :
1.This full stainless steel material chocolate coating machine with hot air pipe ,it is an ideal equipment for sugar/chocolate coating making,it is applicable for pharmaceutical, foodstuff, chemical industries and so on.
- 2. It is popular used in food industry for making sugarcoated pills or nut/peanut and some beans cereal coating surface.
- 3. It also can be used to polish chocolates of various shapes such as cylinders, oblatenesses, ellipsoids, melon seeds and balls to make their surfaces lustrous and colored
2.Working principle of coating machine
This machine consist of main body, worm wheel box, coating pan, heating device,hot air&common blower,electrical equipment, etc.
The transmission process that the motor drive the worm wheel and worm via triangle belt to make the coating pan rotate.Then the material revolve up and down in the coating pan, so that even mixing, pelletizing and polishing can be completed well.
3.Details Parameter for machines
Model |
PG-800 |
PG-1000 |
PG-1250 |
Dia. of Pan (mm) |
800 |
1000 |
1250 |
Rotary Speed of Pan(r/min) |
36 |
32 |
32 |
Power of Fan (kw) |
0.5 |
0.55 |
0.75 |
Power of Heat (kw) |
2 |
2 |
2.2 |
Capacity(kg/time) |
30-50 |
40-70 |
90-120 |
Motor (kw) |
1.1 |
1.1 |
1.1 |
Size (mm) |
800*1000*1520 |
1000*1100*1620 |
1300*1100*1600 |
Weight (kg) |
260 |
270 |
360 |
4.Voltage for machines:
Normally China standard voltage three phase 380V/50HZ ,Single phase 220V/50HZ .But also can adjusted depend on customer local voltage requires .
Payment term: 30% is paid by T/T , the balance 70% is paid before shipment or finished tested .
Quality assured : 1 years quality assured after set up at buyer factory
Installation: We can dispatch Engineer for install machines line to buyer factory , buyer should provide round-trip ticket fee , visa fee , room , food and $80 /day as allowance
Each client can enjoy the following 8 services.
1). At least 1 year from the date of completion of the commissioning. |
2). Free consultation service before, during, and after sales; |
3). Free project planning and design services; |
4). Free debugging of equipment until everything is functional; |
5). Free management of equipments' long distance shipping; |
6). Free training of equipment maintenance and operating personally; |
7). Free new production techniques and formulas; |
8). Provide 1 year complete warrantee and life-time maintenance service; |
Packaging and shipment pictures :
Customer visit our factory and Engineer oversea installation pictures :
