2016 High efficiency Best service corn oil companies, corn germ oil machine manufacturers

FOB Price

USD $1,000 - $10,000 / Set

1 Set(Min.Order)

Supply Ability 10000 Set / Sets per Month
Port Qingdao Shanghai Wuhan
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Usage:	Other, Corn oil	Type:	Other, Cold & Hot Pressing Machine
Automatic Grade:	Automatic	Production Capacity:	30-50T/D	Place of Origin:	Henan, China
Brand Name:	HDC	Model Number:	HDC15	Voltage:	380V/50HZ
Power(W):	300kw	Dimension(LWH):	170013001600	Weight:	780kg
Certification:	CE, ISO	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

2016 High efficiency Best service corn oil companies, corn germ oil machine manufacturers

Product Overviews

Specifications:

1. saving labor
2. suite for soybean press
3. pure oil quality
4. small land-using,low voice
5. used for hot and cold press

Product Description

Operation Process of Oil Press Machine:

1. Prepare raw materials
2. Adjust the machine, i.e. checking electricity, beginning heating (if it is cold pressing,heating is not needed.)
3. Open the machine, put seeds into the hopper.
4. Seeds flowed from hopper into screw bolt, pressing begins.
5. While pressing of oilseeds, crude oil flowed thought the board then into the vacuum filters; and cakes discharged from outlet;
6. Once finished oil pressing, press stop button, then operation finished.

Leaching Section Processing of Corn Germ Oil Extraction Machine:

1. The material (for pretreatment) is sent to rotary extraction by the scraper conveyor. The material will extracted by the solvent or mix oil. After this step, we will get meal and mix oil.

2. Meal is sent to toaster. Through the toaster, the solvent in the meal will separate from the meal. The solvent goes to condenser and is recycled to rotary extraction.
3. After the mix oil from the rotary extraction enters into 1st evaporator and 2nd evaporator, most of the solvent in the mix oil is separated.
4. The mix oil from 2nd evaporator goes to stripping tower and almost all the solvent is separated. From the stripping tower, we can get crude oil and solvent. The solvent is sent to condenser and is recycled to rotary extraction.

The refining section main parts of Corn Oil Machine:
1. Deacidification tank, used for acid refining, alkali refining and hydration
2. Bleaching pot, used for removing off pigments, bleaching oils and grease dehydrate
3. Deodorization pot, used for removing fatty acid and other rare delicacy high efficiently
4. Conduction oil heater, used for providing the heat energy
5. The vacuum pump, used for providing vacuum for bleaching, deodorization which can reach 755mmHg or more
6. Air compressor, used for drying bleaching earth
7. Pressure filter, used for filtering bleaching earth
8. Steam jet ejector pump, providing steam for Deodorization and distillation

Performance of oil expression:

Oil material	Oil press rate (%)	Thickness of the material slag	Residual oil ratio(%)
Sesame	42-55	1.0-1.5	≤7
Peanut	40-50	0.8-2	≤8
Rapeseed	28-43	1.0-1.5	≤8
Sunflower seeds	30-45	1.2-1.5	≤7
Soybean	10-16	0.8-1.5	≤7

Our Services

Engineering design scope of oil pressing machine and sunflower oil press machine and peanut oil press machine

1). Craft flow chart;

2). Equipment layout drawing;

3). Equipment base drawing;

4). Reserved hole & embedded parts drawing and civil engineering condition drawing;

5). Embedded pipeline layout drawing;

6). Embedded pipeline of power circuit drawing;

7). Power electricity layout drawing;

8). Electricity distribution cabinet and operation table schema;

9). Plant layout drawing.

After-sales service scope of oil pressing machine and sunflower oil press machine and peanut oil press machine

1). Equipment installation & commission guidance and training work: buyer offers round-trip

air tickets, VISA fee, salary, local food & accommodation and other related charges for the

engineer.

2). Warranty period: one year, offering long-time free technology service

How to Contact Us?

Send your Inquiry Details in the Below for free sample, Click "Send" Now!

Contact Us

Wuhan HDC Technology Co., Ltd.: Contact nameKathy Lu; Phone86-27-50464122; AddressHongshan Zone, Wuhan, China Wuhan,Hubei
