Help CenterCassava Pelleting Line
Related Products
Specifications
1.High-efficient pellet mill2.CE,GOST,SGS approved
3.Supply assessment
4.One year warranty
Features
1.Gear directly-connecting driving is adopted for high efficiency;
2.Full stainless steel feeder; variable pitch anti-bridging structure; imported FC control;
3.LL stainless steel conditioner with axial steam spraying extends the conditioning and cooking time;
4.Main gear and pinion shaft adopt the carbonizing quenching with high accuracy; smooth driving, low noise and long service life.
5.Gearbox and driving holes'accuracy are guaranteed by specialized casting supplier and NCC.
6.The bearing and oil seal in the main drive are imported, and especially lubrication oil return system is available to ensure reliable bearing lubrication;
7.2 pc quick disassembling type precisely-cast die clamp is adopted to connect the die and quill flange, resulting in convenient and quick disassembling of die;
8.Pellet chamber door and feed chute are fully made of stainless steel with high anti-corrosion ability and long service life;
9.The connection between motor and gearbox adopts new type S-shape spring coupling with more convenient disassembling and assembling and more reliable use.
Main technical parameters
Model |
Capacity (t/h) |
Power(Kw) |
Inner diameter of die (mm) |
||
Main motor |
Feeder |
Conditioner |
|||
RD250 |
0.5-1.5 |
22 |
0.55 |
2.2 |
Φ250 |
RD320 |
2-3 |
37 |
0.75 |
2.2 |
Φ320 |
RD350 |
3-5 |
55 |
0.75 |
3 |
Φ350 |
RD400 |
3-10 |
75/90 |
1.5 |
5.5 |
Φ400 |
RD420 |
3-14 |
90/110 |
1.5 |
5.5 |
Φ420
|
RD508 |
6-15 |
110/132/160 |
2.2 |
7.5 |
Φ508 |
RD558 |
10-20 |
180/200 |
2.2 |
11 |
Φ558 |
RD678 |
25-30 |
220/250 |
3 |
18.5 |
Φ678
|
Animal feed production line
Production Sequence
1. Receiving and pre-cleaning Process
2. Grinding Process
3. Proportioning and mixing process
4. Pelleting Process
5. Sifting and cooling Process
6. Bagging Process
