npk fertilizer granulation disc with best price
1.Introduction of Large Capacity Fertilizer Disc Granulator
Disk grain making machine is a cubage measuring feeding equipment; it supplies materials to the next procedure evenly and continuously; at the same time, it can bear relatively higher pressure. It is a fine powdery material feeder suitable for non-cohesive materials like coal powder, cement, chamotte, limestone, shale, gangue and clunch.
2.Large Capacity Fertilizer Disc Granulator application and advantages
It is widely used in gold concentrator, coal mine, chemical plant, construction and foundry for quantitative and even feeding. Advantages of this machine are: simple structure, easy-to-adjust and excellent in performance. This machine is suitable for conveying of materials with granularity less than 50mm, while it is not suitable for cohesive materials, easy-to-flow or hard-to-flow materials.
3.Main technical parameters
Type(M) |
Speed(R/MIN) |
Capacity(T/H) |
Power(KW) |
Adjustment range(degree) |
weight(T) |
22 |
14.25 |
4-8 |
Y7.5 |
35-55 |
2.85 |
25 |
11.81 |
5-10 |
Y7.5 |
35-55 |
3.25 |
28 |
11.21 |
12-16 |
Y7.5 |
35-55 |
3.71 |
30 |
11.3 |
15-18 |
Y11 |
35-55 |
4.35 |
32 |
9.6 |
15-20 |
Y11 |
35-55 |
5.11 |
36 |
9.1 |
18-24 |
Y15 |
35-55 |
6.51 |
Note:The technical parameters above are just for your reference. If there is any change, all parameters and overall dimension are subject to operating instructions. Any questions please feel free to contact us.
