Specifications
Corn Puff Cereal Machine1.Twin screw extruder
2.Capacity: 120kg/h
3.Extruded and inflated technology
Corn Puff Cereal Machine
1. Production Description
•This processing line adopts the flour, starch, and potato starch as the material then forms a kind of leisure food after extruding, slaking, forming, drying, frying and inflating.
•The screws are made by ally steel and special craft, the screw life is longer, uses building block system structure, may combine willfully.
•The forced lubrication system, by guaranteed equipment transmission longer life.
•Visible auto-temperature controlling system, make the temperature-controlling to be more direct-viewing, parameter to be more precise.
2. Flow chart:
Raw material---mixing---extruding---shaping---cutting---drying---hoisting---flavoring machine
3. Equipments:
Mixer---Screw Conveyor---Extruder---(shaper & core filler)--- Dryer---Hoister---Roller
Parameter |
Mixer |
Extruder |
Core filler |
Shaper |
Hoister |
Five-layer oven |
Hoister |
Oil sprayer |
Roller |
Model |
BFJ-I |
LRS65-III |
JXJ-III |
ZXJ—II |
TSJ |
HGD-5-III |
TSJ |
DPY—II |
SGT--IV |
Installed capacity |
3 |
34.75 |
4.12 |
1.5 |
0.75 |
45 |
0.75 |
2.37 |
1.5 |
Power (kw) |
3 |
20 |
2 |
0.7 |
0.5 |
30 |
0.4 |
2 |
1.5 |
Output (kg/h) |
150 |
130-150 |
150 |
150 |
160 |
150 |
150 |
150 |
150 |
Dimension (m) |
0.9×0.6×1.2 |
2.5×0.8×2.3 |
0.9×0.6×1.6 |
1×0.65×1.1 |
1.3×0.5×0.6 |
5×1.3×2.1 |
1.3×0.5×0.6 |
1.0×0.6×0.8 |
2.1×0.8×1.3 |
4. Package:& Main machine
wooden case :
