Specifications
Corn flakes processing line1.double screw extuder
2.in different shapes and teast
et EU standard
Corn Flakes Processing Line
With the development of our national economy, people’s concepts of time become more intense. The nutrition and convenient of breakfast are paid more attention by people. Using a cup of milk with corn flakes as breakfast increasingly becomes the preferred health food. Our company research and development this process line after researching the developed countries living habits and breakfast development direction of them. All technologies are all reach the level of Europe. The equipment is made to complete the processing from raw material to finished products output at once. This processing line is high degree of automation, it would not damage inside nutrition ingredient of the products.
Flow chart: raw material→ mixing→ helix transferring→ extruding→ cooling and conveying→ air conveying→ tablet → air conveying→ baking →air conveying→ salt frying→ shaking→ elevating→ sugar spraying and flavoring→ leading out→ drying→ cooling and conveying→ packing
Equipment configuration: mixer→ helix transfer→ extruder→ cooling conveyor→ air conveyor→tablet machine → air conveyor→ five-layer oven→ air conveyor→ salt fryer→ shaker→ elevator→ spraying and machine roller→ leading frame→ five-layer oven→ cooling conveyor→ packager
Main single machines’ Parameter of 80-120kg/h
| mixer | Helix transfer | extruder | Cooling conveyor | Tablet machine | Air conveyor | Three-layer over | elevator | Salt fryer | shaker | roller | Spraying machine | Leading frame |
Installed capacity | 4 | 1.1 | 35 | 0.55 | 5.5 | 1.1 | 30 | 0.75 | 6 | 0.25 | 0.75 | 4.12 | 0.75 |
Driving power (KW) | 3 | 1.1 | 24 | 0.55 | 3.5 | 1.1 | 20 | 0.75 | 4 | 0.25 | 0.75 | 4.12 | 0.75 |
Dimension(mm) | 900× 600× 1200 | 2600× 600× 1900 | 2600× 900× 1900 | 5000× 650× 1000 | 1800× 1600× 1300 | 700× 550× 600 | 5000× 1250× 1750 | 2100× 500× 1200 | 3580× 1700× 3000 | 1300× 600× 700 | 2100× 800× 1300 | 800× 550× 1600 | 4000× 1250× 1600 |
Main single machines’ Parameter of 300kg/h
| mixer | Helix transfer | extruder | Cooling conveyor | Tablet machine | Air conveyor | Five-layer over (5m) | elevator | Salt fryer | shaker | roller | Spraying machine | Leading frame | Five-layer oven (8m) |
Installed capacity | 4 | 1.1 | 130 | 0.55 | 5.5 | 2.2 | 45 | 0.75 | 6 | 0.25 | 0.75 | 4.12 | 0.75 | 60 |
Driving power (KW) | 3 | 1.1 | 120 | 0.55 | 3.5 | 2.2 | 35 | 0.75 | 4 | 0.25 | 0.75 | 4.12 | 0.75 | 50 |
Dimension (mm) | 900× 600× 1200 | 2600× 600× 2400 | 4300× 900× 2400 | 5000× 650× 1000 | 1800× 1600× 1300 | 700× 550× 600 | 5200× 1250× 2100 | 2100× 500× 2100 | 3580× 1700× 3000 | 1300× 600× 700 | 2100× 800× 1300 | 800× 550× 1600 | 4000× 1250× 1950 | 8000x 1250x 2100 |
single machine
simple:
