Manufacture of Bicycle Engine Kit---Hot Selling
The kit include everything to change bike into moped
CDH 4 Stroke Gas Motor Bike Engine Kit
Bicycle Engine Kit include:
1. 4 stroke engine
2. Black Gas Tank (2L)
3. Muffler
4. Bike Chain
5. Chain Guard
6. 44 Tooth Sprocket with 9 Holes
7. Throttle handle
8. Throttle Cable
9. Fuel hose
10. Tank value
11. Clamping grubber assembly
12. Engine Bracket
13. Chain idler assembly
14. Crank and pedal
15. All the Needed Mounting Brackets, Gaskets, and Hardware
SPECIFICATION
Engine type | Air-cooled 4-stroke OHV single-cylinder |
Displacement | 49.1cc |
Bore X Stroke | 41.8 X 35.8 mm |
Maximum Power Output | 2hp(1.5kw)/ 6,800rpm |
Compression Ratio | 7.4:1 |
Carburetor | Float Type |
Ignition | Transistorized Magneto |
Starting System | Recoil Pull-Start |
Fuel Type | Regular Unleaded Gasoline |
Fuel Tank Capacity | 5 Gal (1.89L) |
Lubrication System | Forced Splash |
Oil Capacity | 8.48 ounces (250ml) |
Engine Oil | SAE 10W30 |
Air Filter | Semi-dry |
Throttle | Twist-Grip |
Clutch | Automatic Centrifugal |
Transmission | Shiftless Reduction Gearbox |
Final Drive | Chain-drive |
