Popular rabbit food pellet making machine

 QI E rabbit food pellet making machine  for chicken, cattle,horse,duck etc with small and large scale production.

Final pellets size range:1-12mm(For reference)

1.For pig feed pellet diameter: ø3.5-6.5mm

2.For cattle feed pellet diameter: ø4.5-8mm

3.For broiler chicken feed pellet diameter: 3.2mm

4.For fish feed pellet diameter: ø2/2.5/3mm

5.For shrimps feed pellet diameter: ø1-3.5mm

rabbit food pellet making machine   process flowchart:

Raw Material → Feed Grinding → Feed Mixing → Feed Pelletizing → Pellet Cooling → Pellet Crushing → Screening & Grading → Pellet Packing

A.  The cleaning section of rabbit food pellet making machine    :

 Feed machinery ---cleaning section:
Before going into the main equipments,the raw materials should be cleaned to remove impurities and iron parts in order to ensure the product quality and normal working of the main equipments.

The raw material go through the bucket elevator, then it will be lifted into a certain height, then it goes into the pre-cleaner, in which the impurities can be removed; then the clean material goes into the permanent magnetic sleeve, in which the iron things are removed, then clean material goes into the crushing section.

B.  The crushing section of rabbit food pellet making machine   :

The task of this section is to crush the clean materials we got in the last section into powder,and then deliver the powder to the next section.

C.  The mixing section of rabbit food pellet making machine   :

 The task of this section is:

1. evenly mix different materials into complete powder feed.
2. According to the certain operation order between the bin for the mixer, the mixer and the buffer bin,to ensure the continuous operation.

D.  The pelletizing section of rabbit food pellet making machine   :

The task of this section is to pelletize the powder feed to required sizes feed pellets.

 E.  The cooling section of rabbit food pellet making machine  :

The pellet with high temprature output form the pelleting machine, about 70-90 degrees Celsius, the cooling machine is needed to reduce the temprature for the pellets storing, our counter flow cooler is the usual type of the cooling machine for the pellets, it can give the better result in a short time, with low energy cost.

F.  The packing section of rabbit food pellet making machine   :

This machine is need for the wood pellets production plant, that make the pellet in best storing and transporting, reducing the break of the pellet wood.

H.  The power control of rabbit food pellet making machine   :

E: mixer machine for  rabbit food pellet making machine
