Hydraulic sunflower seed edible oil press machine
- 20 Set / Sets per Month
- Qingdao or other ports
- T/T L/C D/P D/A Credit Card PayPal
- used for stone pe-250x400 quartz small jaw crushers
- low comsuption mini rock diesel engine jaw crusher
- china manufacturer provide used jaw crusher price
- high efficiency pe 400 x 600 old mini jaw crusher for sale
- manufacturer provide toggle platepe 150x250 jaw crusher machine
- pe 400x600 mobile jaw crusher price with spare parts
Product Details
Condition: | New | Usage: | Sunflower Oil | Type: | Other, Cold & Hot Pressing Machine, sunflower seed cake oil solvent extraction |
Automatic Grade: | Automatic | Production Capacity: | 30TPD-1000TPD | Place of Origin: | Henan, China |
Brand Name: | QIE | Model Number: | 6YY-260 | Voltage: | According to customer demand |
Power(W): | According to project | Dimension(L*W*H): | According to project | Weight: | According to customer demand |
Certification: | ISO9001-2008 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Hydraulic sunflower seed edible oil press machine
sunflower seed cake oil solvent extraction
1, sunflower seed cake oil solvent extraction brief introduction
2, sunflower seed cake oil solvent extraction main equipment
1. Solvent pumps: continuously spray solvent to the rotary-typr extractor.
2. Solvent extractor: spray and soak the soybean cake with solvent so that oil fats can be dissolved
in solvent (form miscella). After processing, you can get wet meal and miscella (mixed oil).
3. DTDC: used to separate the solvent from the wet meal.
4. Miscella tank 1st: pump the miscella ( oil with solvent) into the miscella 1st, then add 10% saline
water to it. The phospholipid and impurities in the miscella will react with the saline water, at last
the reactant precipitate, reaching the goal of purifying.
5. Miscella tank 2nd: the purified miscella will be pumped into it.
6. Miscella stripping: it will remove the remaining solvent in miscella. And the solvent will be
discharged to condenser for recycling.
7. Condensers: used to cooling the solvent gas separated from the wet meal and miscella for recycling.
Solvent Extractor Advantages:
1) The material is divided into several independent units on the material bed, which can effectively
prevent miscella at all levels from fleeing hither and thither on the material layer and ensure the
concentration gradient between several sprays.
2) Immersion area appears in each lattice, which can help achieve better immersion effect.
3) The chain box is supported by track and can prolong the service life of screen deck by not
touching it.
4) The towline extractor is driven by world leading double-shaft hydraulic motor, with balance force,
reliable operation and less maintenance cost.
5) Specialty suitable for the extraction of high oil and high power materials, and better immersion
effect can be expected for ordinary oil plants.
Desolventizer toaster advantages:
a) Passivate and damage the anti-nutritional components such as the urea enzyme and trypsin
in the meal, and improve meal value in use.
b) Control the protein denaturation degree in the meal , and improve the NSI index effectively.
c) It can better regulate the color, flavor and taste of the meal.
d) It can better reduce residual solvent in the meal and regulate the meal moisture, so as to
guarantee the minimum solvent consumption and safe use of the meal.
Negative pressure evaporation process
The liquid from the extractor is the miscella containing grease and oil, which can be separated
out according their different vaporization temperatures. Our company mainly uses vacuum
evaporation technology, and it can reduce solvent leakage and consumption. The separated
solvent vapour is cooled and recycled back to the extractor for reuse, which can improve the
solvent efficiency.
3, sunflower seed cake oil solvent extraction technical parameters
Requirements for extraction material,steam,water,electricity etc:
1,moisture of extraction material :5-8%;
2,Temperature of extraction material: 50-55°C;
3,oil content of extraction material: 14-18%;
4,thickness of extraction cake: ≤ 13mm;
5,Powder degree of extraction material: ≤ 15% (30 meshes);
6,steam:: ≥ 0.6Mpa;
lvent: national standard No.6 solvent oil;
8. Power electricity: 50HZ 3*380V ;lighting electricity:50HZ 220V ;
9.Temperature of supplement water: ≤ 25 °C hardness: ≤ 10;
10.Volume of supplement water: 1-2 m3 / t raw material;
11.Temperature of recycle water: ≤ 32 °C.
Company Information
Our Strength
1, Established in 1982, we have more than 30 years experience. Our goal is to be pioneer in global grain and oil
industry.
2, We have deep cooperation with Henan Machine Design Research Institute and Henan University of
Technology. Our professor often go abroad attending grain and oil conference and forum.
3, We have completed service line including technical department, engineering department, project department,
electronic commerce department, domestic trade department and foreign trade department. After signing
contract, we will set up special team including engineers, installation technicians, drawing designer,
business person, after-sales service person, and so on. We will provide one-to-one service.
Our Service
Whole set of equipment for production line.
Motor and power control system.
Installation material.
Installation and test-run.
Drawing of process description, equipment layout, foundation and
hole, construction.
Drawing of power control.
Isolation and painting for equipment.
Water recycling and cooling system outside the plant (i.e. supplementary device).
Staff training and long-term technical service.
Main Business Field
- 10-500T/H oil material primary cleaning,drying and storage section turn-key project.
- 100-3000 T/D oil pretreatment, shelling and pre-press workshop turnkey project (soybean hot dehulling, bean skin crushing, the soybean extrusion, high oil contained pre-pressed cake extrusion and high oil contained flakes puffed directly). Rice bran turn-key project.
- 100-3000 T/D leaching workshop turnkey project (towline extractor, rotocel extractor, loop type extractor,
- DTDC separated machine, the full negative pressure evaporation,
- Paraffin wax recovery, leaching workshop degumming, phospholipid concentration).
- 30-1000T/D continuous physical (chemical) refining line.
- 20-3000T/D sunflower oil, rice bran oil, corn germ oil dewaxing turnkey project.
- 10-200T/D fatty acid esterification edible oil production line.
