the best selling rapeseed oil prepressing and pressing machine in Canton Fair
Introduction of Oil Press Machine:
Main spare parts: worm, squeezing head, worm shaft, cage bar, heater ring, cake outlet, vacuum filter.
Main Features & advantages:
1. High oil yield, low oil residual in cake. The oil left in cake is less than 6%; Cake thickness can be adjusted while machine stops running;
2. Small-land using: only 10-20 square meters workshop can make production.
3. Pure oil quality: machine surface is made of chrome plated stainless steel, in line with food hygiene standards; Besides, with two vacuum oil filters, residual can be removed by simple filtering;
4. Labor saving: it can save 60% labor for equal output and 40% labor cost per day, for one or two people are able to make production .
5. Environment friendly: integrating advantages of traditional oil press machine, the new design machine are noiseless, no pollution, which can better meet environmental standard.
6. Other advantages: high efficiency, energy and labor saving, easy operation, simple maintenance.
Working Principle:
Press operation, enter the press bore from the hopper after processed oil. By pressing the spiral turn embryos continued to advance, pressing. The blank is carried out in the state of motion under the press of the squeezing chamber in the squeezing chamber, high pressure conditions, the friction resistance between the great blank and screw, blank and pressing chamber, so that the blank micro material between the friction caused by the relative motion. On the other hand, because the screw root circle diameter is gradually thickening, pitch is gradually reduced, so when the screw rotation, screw hard material embryo that can move forward, and can turn outwards, and close to the screw thread surface material layer with the shaft rotation. So in the squeezing chamber for each blank particles are not the same speed, direction of movement, but also there is relative motion between the particles. The heat generated by friction and meet the required oil technique operational heat, contribute to the protein thermal denaturation of the blank, destruction of the colloid, plastic increased, while also reducing the viscous oil to some easy to precipitate, thus improving the oil press oil rate, make the juice out of the oil pressure, and from Park row gap and gap outflow discharge.
CE certification (CONFORMITE EUROPEENNE) and BV certification(Bureau Veritas):
CE certification (CONFORMITE EUROPEENNE):
BV certification(Bureau Veritas):
Certificate of Registration:
Any more questions, please contact me.
