Specifications
1,Easy to operate2,Low maintance
3,Long service life
[Product name]JF Series Liquid Recovery Tank
[Product introduce]
The company's JF series batching tank using 316L or 304 manufacturing, advanced technology, high degree of
automation, in line with national GMP certification requirements. Tank body adopts the design of vertical double
layer structure, the polishing of Ra0.45, the overall smooth without dead angle. External use of mirror panel or
matte board insulation, tank gloss consistent. The Miller board interlayer steam heating or cold water cooling and
filling insulation material, where the over current components are made of 316L material, the rest of the 304 material.
The inner tank top and bottom
head for the dish, the partial wall axial flow stirring, the top of the tank water inlet, a feed inlet, with return flow,
disinfection, cleaning ball, manhole, and install the 0.22um air respirator and mixing system. The bottom of the
tank body, a sewage outfall, sampling, temperature sensor, liquid level sensor. With the control cabinet, liquor
temperature detection and display, temperature control. Detection of the height of liquid level and display,
alarm and other functions, provide. The company is China Pharmaceutical Equipment Industry Association as
the "medicinal ingredients can" industry standard unit and passed.
