Specifications
1.With high efficiency, convenient operation2. For the preparation and storage of materials
[Product Name]JFM Series Preparation Tank
[Product introduce]
This equipment is suitable for pharmaceutical, food, chemical and other industries, for the preparation and storage of materials.
Overview
This equipment is composed of tanks, jacket, mixing system and other parts. Only within the jacket steam or cooling water is piped in, in under the action of stirrer, make material to fully mix. With high efficiency, convenient operation, etc.
Main technical parameters
Model | JFM-1000 | JFM-2000 | JFM-3000 | JFM-4000 | JFM-5000 | JFM-6000 | JFM-10000 |
Volume(L) | 1000 | 2000 | 3000 | 4000 | 5000 | 6000 | 10000 |
Designed pressure in tank(MPa) | <0.1 | ||||||
Sandwich design pressure(MPa) | <0.1 | ||||||
Heat transfer area(m3) | 4 | 5 | 6.5 | 8 | 10 | 12 | 18 |
Machine size(m) | Φ1*1.2 | Φ1.2*1.5 | Φ1.4*1.6 | Φ1.5*1.8 | Φ1.6*2 | Φ1.6*2.5 | Φ1.8*3.5 |
Note: Above parameters for reference, the actual parameter in the drawing date.
