MT-200 Automatic Round Bottle Labeling Machine
MT-200 vertical round bottle non-dry tape marking machine, in order to achieve rationalization of production target
and design. Labeling process automation, simple operation, the production speed is quick, labeling positionbeautiful neat, For pharmaceutical, chemical and foodstuff trades etc circular vessels labeling
Working principle and structural features
Will different packing objects into labeling machine belt conveyor, by driving a bottle into the bottle conveying
institutions, continuous motion by depending on fiber detected after bottle, photoelectric signal transmission to PLC
by PLC output signal processing will lose to the stepping motor, the standard of stepping motor, through the rolling
institutions will stick son, tag labeling of objects by labeling machine conveyor belt into the next procedure or
containers.
Host adopts stepping motor driver, sets of (Taiwan) PLC control system, sets of (Taiwan) touch people interface
keyence fiber (Japan) device etc imported components, gathers numerous leading technology, make it become the
industry has the advantage of technology products. Microcomputer automatic control, interface screen friendly
human-machine interface, ingenious mechanical structure, make the operation simple and powerful function, Can
realize tag number, counting, set print control, labeling, lack of control, marking, colorless such abnormalities
automatic detection and alarm functions, Random capacity and the quantity management label, Adjust tightness
labels, The length and tags, Host height and adjust position before, Optional ribbon typewriter one, Labeling and tag with reaction degree detection. The machine adopts high quality T6 aluminum and stainless steel SUS304, well
made, in conformity with the requirements of GMP. LM - ST vertical non dry tape marking machine is a very good
price.
Poster speed | 0-200 PCS/min |
Bottle diameter | 20 - 100mm |
Bottle Height | 25-350mm |
Label size wide | 10-140mm |
Label size length | 15-200mm |
Labeling precision | ±1mm (depending on the bottle degree, perpendicular round) |
Labeling diameter(Max) | 300mm |
Power supply | AC110V / 220V. 500W |
Machine size | 2000*1300*1500mm |
Weight | 200kg |
Printing device | HP 260Q -(optional) |
Guangzhou Jinfeng Light Industry Machinery Co., Ltd. is a manufacturer that produces cosmetic, pharmaceutical, chemical and dairy equipment. We undertake equipment design, manufacture, installation, maintenance, technical improvement support, technical consultancy and other services. Our main products are vacuum homogeneous emulsifying machines, reverse osmosis water treatment machines, automatic and semi-automatic filling machines and all kinds of stainless steel tanks. All of them are of reliable quality and good effect. We have more than ten years' experience in machinery manufacturing and our products have been entered into domestic and overseas markets. The diverse products with high quality can meet various needs of industries mentioned above.
If you are not satisfied, Don't be disappointed,u can tell us ur request and we will recommend one to u. And also can customized, our engineer can exclusively design for u.Thank u for ur inquiry !
