2015 JF Movable lifting type homogenizer
Specifications
pneumatic lifting homogenizer
1.precision finishing stator and rotor
2.SUS304,SUS316L
3.disperser,homogenizer,emulsifier
Homogeneous machine is mainly used for the field of biotechnology medicine field organization dispersed
sample preparation, food industry enzyme treatment and in the pharmaceutical industry, cosmetics
industry paint industry and petroleum chemical industry etc.. The device adopts stainless steel system,
can effectively separate body and the surface of the sample is included microbial homogeneous samples,
samples were packed in disposable sterile homogeneous bag, not with the instrument contact, satisfied thefast speed, accurate result, good repeatability requirements.
The device adopts stainless steel system, microbe homogenous sample can effectively separate body and
the surface of the sample is included, samples were packed in disposable sterile homogeneous bag, not with
the instrument contact, with soft homogenization, the sample without pollution, no damage, no heating, no
sterilizing treatment, no need to wash the utensils, satisfied fast speed, accurate result good
repeatability requirements. This product is suitable for tumor tissue (such as liver cancer, gastric cancer, colon cancer breast cancer) the homogenate, can get a large number of single cells (2 minutes up to 2*10), when necessary can prolong the time of homogenization, tissue cells (such as liver etc.) to realize soft
broken.
1) With precision of the rotor and the stator, a working head (stator and rotor forgings manufacturing)
claw type structure, two-way suction, cutting high efficiency.
2) Intermittent type high shearing dispersion emulsifying homogenizer is through the rotor speed smooth
rotation, the formation of high frequency, strong circumferential tangential velocity, angular velocity
and other integrated kinetic energy.
3) Effectiveness: in the stator, rotor under the action, set reasonable narrow gap in the formation of
strong, reciprocating hydraulic shear, friction, centrifugal extrusion, liquid flow collision comprehensive
effect, materials in the container move in circles above process, obtain the final product.
Basic Characteristics
1) Stable operation, low noise, convenient cleaning, mobile and flexible, can be used continuously, for
material can be ultrafine dispersion, emulsification. Can be widely used in industrial production of
emulsification homogenization and dispersion.
2) Can make liquid in the crowded research. The strong impact and pressure loss expansion under three
action to make the material quality refinement of mixed. This equipment is an important equipment of
dairy food. Beverage industry.
3) Use for milk, soy milk and other kinds of dairy drinks, homogenized under high pressure, can make the
fat globule significantly refined dairy liquid, make the products after eating easy digestion and
absorption, improve the use value.
4) Use for ice cream and other products of the production, can improve the liquid fine cleanliness and
looseness, the intrinsic quality improved obviously.
5) Use for emulsions. Glue. Juice. Slurry production, can prevent or reduce the material liquid stratified,
improve the appearance of liquid material, which is more brightly colored, sweet degree more thick
taste more alcohol.
Application of industry
1) Applied to biological medicine; food industry; daily care products; coating ink; nanometer material
petrochemical; auxiliaries; paper industry; pesticide and fertilizer; plastics and rubber; power
electronics; other fine chemical industry.
2) Homogenizer application in soy milk: homogeneous when the soy milk under high pressure from slit
extrusion homogenizing valve. The fat globules, protein particles in shear force, joint impact force and
hole effect, fining. Formation of dispersion and uniform. To prevent the floating fat, protein
precipitation, increasing soy milk gloss, improve product stability.
3) Homogenization of soy milk by homogenization pressure. Effect of homogenization temperature and
homogenization times three factors. Homogeneous pressure limitation of equipment. Milk production is
available in the 20~30MPa pressure homogenizing. Temperature control is more suitable for the general
homogeneous at 55~65 deg. Homogenizing frequency 1~2 times.
Model |
Power (kw) |
Rise/fall height(mm) |
Speed (R.P.M) |
Mixing volume(L) |
Impeller diameter (mm) |
Weight (kg) |
JFL600-1.5H |
1.5 |
600 |
A:0-1500
B:0-3000 |
10-50 |
Φ100 |
250 |
JFL600-2.2H |
2.2 |
20-60 |
Φ150 |
300 |
||
JFL600-3.0H |
3.0 |
800 |
20-100 |
Φ200 |
330 |
|
JFL600-4.0H |
4.0 |
20-100 |
Φ200 |
380 |
||
JFL600-5.5H |
5.5 |
1000 |
50-300 |
Φ200 |
400 |
|
JFL600-7.5H |
7.5 |
50-300 |
Φ200 |
450 |
Guangzhou Jinfeng Light Industry Machinery Co., Ltd. is a manufacturer that produces cosmetic, pharmaceutical, chemical and dairy equipment. We undertake equipment design, manufacture, installation, maintenance, technical improvement support, technical consultancy and other services. Our main products are vacuum homogeneous emulsifying machines, reverse osmosis water treatment machines, automatic and semi-automatic filling machines and all kinds of stainless steel tanks. All of them are of reliable quality and good effect. We have more than ten years' experience in machinery manufacturing and our products have been entered into domestic and overseas markets. The diverse products with high quality can meet various needs of industries mentioned above.
If you are not satisfied, Don't be disappointed,u can tell us ur request and we will recommend one to u. And also can customized, our engineer can exclusively design for u.Thank u for ur inquiry !
