Plastic tube filling machine, plastic tube sealing machine for cosmetic, pharmaceutical, chemical product
Overview and Use
JF-MC Plastic (composite) hose and sealing machine is mainly used for a driving principle. Use segmentation mechanism driven turntable mounted fixture for intermittent operation, automatic filling and complete internal and external heating, sealing, play yards, trimming, finished withdraw a series of functions. Filling accurate measurement, the heating time is stable, adjustable, sealing beautiful appearance, neat, strong, health, trimming smooth.
The machine is set for 10-bit, in addition to the artificial tube, the other can be done automatically. Stable and reliable, no noise and other pollution.
Where the whole contact material and certain related parts are made of high quality stainless steel production, the need to clean parts are made of quick-change device, easy washable. Where some material need heating insulation, which can be equipped with external barrel heating thermostat. Any use of plastic pipe and composite pipe materials as a packaging material, you can rest assured that the choice of aircraft. Cosmetics industry, medicine, adhesive industry, shoe polish and other industries as well as other relevant sectors chosen a good product.
Suitable for: oils, hair care, skin care category, cosmetics, cleaning, detergent, toothpaste, glue, syrup, liquid alcohol
Applicable industries: cosmetic, pharmaceutical, chemical
The main application of technical invention
1.Plastic (composite) hose in the heating system, using electric copper block heat and synchronous, hot air nozzle inner wall of the tube evenly heated through. Than in the past using only the outside of the tube heating method to learn advanced a lot. Sealing fastness also increased significantly. The two methods were compared, the outer heating, wall heat from outside to inside, and outside the big error, especially tube wall temperature is certainly lower than the outer wall, and sealing and pressure in the process of code, often caused by adhesion or sealing fastness instability is a major flaw, greatly improving the sealing pressure and code quality.
2.The machine adopts external heating nip reciprocating scissors principle, to pass on the road for a good bit internal heating pipes in the wall and then external heating to heat the plastic wall conditions further improved, creating for subsequent sealing, pressure code a very perfect sealing conditions.
3.Sealing and coding. Also used by the reciprocating cylinder drive scissor mechanism, the heated plastic pipe (composite tube) nip sealed, according to the production batch number and date stamp exchange. Since the plastic tube inside and outside temperature equilibrium, the sealed tube end is very clear strong and can withstand considerable pressure will not break disengaged, while ensuring product quality and credibility of the user, which is all desired by the user.
4.Trimmed means. After the plastic pipe (composite tube) Sealing press code, the trailing end portion is not always neat, it must be cut. The device has a fixed blade and driven by a cylinder with a certain inclination of the movable blade cut the tail, the tail end of the product neat, attractive and improve the appearance of consumer products observability.
5.Machine transmission principle
This machine consists of an electric motor as the main driving force, through a turbine speed reducer and frequency control, through the splitter gear for intermittent operation, so that is mounted on the turntable 10 clamps for isometric exercise. After the artificial tube, filling material can be carried out, the entire filling system uses the cylinder drive, and a metering adjustment screw, can be adjusted within a certain range of measurement accuracy of up to ± 1%. To avoid material things outside drops, the machine adopts filling nozzle is inserted in the form, but also by the lift cylinder to complete the advance and retreat work.
Those who have been filling the pipe, while importing for the next bit, simultaneously inside and outside heated nip, play yards, trimming, top out, everything is done at the same time, so the machine for each rotation a bit, while completing a product, the maximum production capacity of up to thirty one minutes.
All filling, internal and external heating, lamination, cutting, ejection, by division, solenoid valve control actions required to complete the entire running conditions stable, reliable, repeatable performance, the action in place up to 100% without a mistake, safe, reliable, easy to operate. After all users are satisfied after use, generally good response.
Technical parameters
Note : In case of inconformity of the data in the form due to technical improvement or customization , the real object shall prevail.
