Qingdao HEGU Plastic Machinery: SJ Series of Single Screw Extruder

Qingdao Hegu Wood-Plastic Machinery Co., Ltd.
Qingdao HEGU Plastic Machinery: SJ Series of Single Screw Extruder thumbnail-1
Qingdao HEGU Plastic Machinery: SJ Series of Single Screw Extruder photo-1
US$ 10,000 - 70,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Board/sheet/rob/tube/pipe and other special shapes
Plastic Processed:
Other, PP/PE/PS/PC/HIPS/PA/EVA/ABS etc.
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Other, Board/sheet/rob/tube/pipe and other special shapes
Plastic Processed Other, PP/PE/PS/PC/HIPS/PA/EVA/ABS etc.
Screw Design Single-screw
Automatic Grade Automatic
Place of Origin Shandong, China
Brand Name HEGU
Model Number SJ-30/45/65/90/120/150
Voltage 380V 50HZ or other area special requests
Power(W) 3~315kw
Dimension(L*W*H) 3~6m*2m*3m
Weight 1~2.5tons
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Product Application on Plastic Machinery: SJ Series of Single Screw Extruder
SJ series of single-screw extruder is appropriate for producing such products with thermoplasticity as pipes of PP, PE, PS, ABS, PMMA, PVC, as well as plates, sheets, rods, profiles and plastic pellets. According to different raw materials and product specifications, screws are adopted with different ratios of length diameter and compression and barrels are of different structures .Proper barrels, screws and driving mechanism are adopted so as to realize high-quality final products production.

Model
SJ-30B
SJ-45B
SJ-65B
SJ-90B
SJ-120B
SJ-150B
L/D
30 33
25 30 33
25 30 33
25 30 33 35
25 30 33 38
25 30 33 38
Screw RPM
15~90
15~90
10~90
10~90
8~80
8~80
Motor power (kw)
3~5.5
5.5~10.5
18.5~90
45~185
90~250
110~315
Max output (kg/h)
16
40
300
600
800
1200
Heating power (kw)
5~8
7.8~12
12~18
16~40
32~55
45~75
Cooling mode
Fan or water cooling
Products Show

The excellent features on Plastic Machinery: SJ Series of Single Screw Extruder

SJ series of single-screw extruder is appropriate for producing such products with thermoplasticity as pipes of PP, PE, PS, ABS, PMMA, PVC, as well as plates, sheets, rods, profiles and plastic pellets. According to different raw materials and product specifications, screws are adopted with different ratios of length diameter and compression and barrels are of different structures .Proper barrels, screws and driving mechanism are adopted so as to realize high-quality final products production.
● High output and low power consumption.
● All hard teeth surface bears experienced heat treatment and fine grinding, the reduction box together with the inner forced cooling system ensure high efficiency, low voice and long lifespan.
● The screw has been designed with reasonable geometric parameter. Corresponding to different raw materials and products, screws with different ratios of length diameter and structures are selected to meet different request of clients.
● In accordance with different requirements of raw materials, the heating section of material barrel has two structures i.e. slot section and smooth section.
● Both screw and barrel are made of alloy steel with excellent properties, which have advantages of abrasion resistant, anti-corrosion and high strength.
● The whole set is of reasonable and standard structure, which ensures convenient operation and easy maintenance.

Our Service

Engineers team

Engineers available to service machinery

overseas, free within one year quality guarantee, and $100/day after one year.

Software updating

Life long technical support. Improving our technology on the machine part, process and software for much smarter.

24hour online maintain

Anytime on line trouble shooting by telephone and email for saving your time and cost.

Our Company

Factory

Workshop


Packing & Delivery

Packing Details  : For single screw extruder, it is standard sea-worthy packaging, pallets with film, plywood box for electrical parts and quick-wear parts.

Delivery Details : 30 days after received the 30% down payment, also according to order planning.

Our Certifications
Customer Photo

Customers overseas

We have a lots of aboard customers with high speak of our PVC Semi Skinning Foam Board Extrusion Production Line and products, they are mainly in Russia, Australia,

Singapore, USA, Malaysia, Indonesia, Iran, Italy, Mexica, and other countries of North and South America, East

Asian, West Europe, Africa, and so on.

FAQ
Payment terms
30% down payment after signing the contract within 5 workdays, the rest 70% payment after test run in our factory and before shipment.
Accepting& inspecting
in seller's factory
Bring into the agreed time, it is in seller's factory to accept and inspect the PVC Semi Skinning Foam Board Extrusion Production Line. The test run will make the pipes under two sides discussion, and promise the machine works in succession for two hours. Other special request, negotiate by two sides. The charge of test materials should be paid by buyer side.
Installation&test-run
in buyer's factory
1) User should prepare the SJ series single screw extruder operators and tools for machine installing, and make the energy available such as water, electricity, materials, work space, labors and so on.
2) Seller send one engineer for direction and supervising the installing, test run and training. The test run will be finished in 15 days if there is other requests please inform in advance.
3) The buyer should pay $100 per day as subsidy for the engineer, and in addition the round airplane tickets, food, hotel fee and insurance of the engineer during the installation and test-run period.
Documents supply
Mechanical and electrical operation manual(1),
Electrical connection drawing(1),
And Operation technique manual(1).
In Chinese-English bilingual version.
