Specifications
snack food drying machinestainless steel net belt conveying system
multi-layer
electricity/diesel/gas/LPG dryer
150~300kg/h
snack food drying machine
**** Characteristics of Electricity Dryer
1. Heat with infrared ray heating tube, raise and lower down temperature quickly, small heat inertia and high heat efficiency.
2. Adjustable transit speed of net belt with accurate temperature control device.
3. Double-roller chain and chain drive make stable and smooth running.
4. Sliding board bottom of dryer for easy cleaning.
5. Suitable to dry non-fried extrusion snacks, nutritional powder, bread crumb, pet food, soybean protein, etc
Model |
DKX |
DKX-II |
WHX-III |
Capacity |
100-150kg/h |
100-200kg/h |
200-350kg/h |
Installed power |
22kw |
37kw |
45.37kw |
Heat power |
21kw |
36kw |
42kw |
Heat temperature |
200 |
200 |
200 |
Drying time |
48min |
510min |
817min |
Dimension |
4800×1150×1750mm |
6700×1150×1750mm |
7200×1400×2500mm |
****Characteristics of Multi-layer Diesel/Gas Dryer
1. High efficient diesel/gas burner can heat swiftly with low consumption and high heat efficiency. 2. Hot wind cycle device makes heat energy equally in the dyer.
3. Adjustable transit speed of conveyor belt with accurate temperature control device.
4. Double-roller chain and chain drive make stable and smooth running.
5. Sliding board bottom of dryer for easy cleaning.
6. Suitable to dry non-fried extrusion snacks, nutritional powder, bread crumb, pet food, soybean protein, etc.
Model |
SHX |
SHX-II |
WHX |
Capacity |
200-250kg/h |
200-250kg/h |
200-350kg/h |
Total power |
4.47kw |
5.1kw |
5.57kw |
Burner |
1.2×105kcal |
1.2×105kcal |
1.5×105kcal |
Diesel consumption |
68kg/h |
68kg/h |
710kg/h |
Heat temperature |
250 |
250 |
250 |
Drying time |
414min |
515 min |
725 min |
Dimension (mm) |
6500×1500×2500 |
9000×1500×2500 |
7200×2100×2600 |
