Help CenterStainless Steel Food Vegetable Fruit Drying Machines
Related Products
-
Electricity / Diesel / Gas / LPG DryerNegotiableMOQ: 1 Piece -
Food Dryer Extrusion Snack Drying Machine (100-400kg/h)NegotiableMOQ: 1 Piece
-
Potato Chips Drying MachinesNegotiableMOQ: 1 Piece
-
Dog Chewing Food Drying MachinesNegotiableMOQ: 1 Piece
-
Corn Flakes Drying MachinesNegotiableMOQ: 1 Piece
Specifications
1.dryer used for snack food,fruit,vegetable2.electricity,gas, diesel,LPG as power
3.different design for different demands
Different dryer used in different demands
DKX-I(3-layer electricity dryer)
DKX-II(3-Layer exlectricity dryer-longer)
WFX-III(Recycling dryer)
Technical Parameter of electricity dryer
Model |
DKX |
DKX-II |
WHX-III |
Capacity |
100~150kg/h |
100~200kg/h |
200~350kg/h |
Installed power |
22kw |
37kw |
45.37kw |
Heat power |
21kw |
36kw |
42kw |
Heat temperature |
~200°C |
~200°C |
~200°C |
Drying time |
4~8min |
5~10min |
8~17min |
Dimension |
4800×1150×1750mm |
6700×1150×1750mm |
7200×1400×2500mm |
SKX(3-Layer Diesel dryer)
SKX-II(3-Layer diesel dryer -extended)
GHJ-W(High temperature dryer)
Static dryer
Model |
SHX |
SHX-II |
WHX |
WFX-II |
GHJ-W |
XR |
Capacity |
200~250kg/h |
200~250kg/h |
200~350kg/h |
200~400kg/once |
Adjustable |
100~120kg/once |
Total power |
4.47kw |
5.1kw |
5.57kw |
5.03kw |
0.55kw |
0.55kw |
Burner |
1.2×105kcal |
1.2×105kcal |
1.5×105kcal |
1.2×105kcal |
24× |
8×104kcal |
Diesel consumption |
6~8kg/h |
6~8kg/h |
7~10kg/h |
5~7kg/h |
6.5m3/h(LPG) |
3~5kg/h |
Heat temperature |
~250°C |
~250°C |
~250°C |
~150°C |
~800°C |
~100°C |
Drying time |
4~14min |
5~15 min |
7~25 min |
Set respectively |
3~9 min |
Set respectively |
Dimension (mm) |
6500×1500×2500 |
9000×1500×2500 |
7200×2100×2600 |
7500×2400×2000 |
3500×1500 |
400×1200×1000 |
Also we can design the dryer upon on customer request.
Jinan Dayi Extrusion Machinery Co., Ltd. Is the advanced professional manufacturer of Extrusion Food Machinery in China.
Our single-screw & double-screw extrusion machines have been used to produce a lot of snacks, such as, extrusion leisure snacks, breakfast cereal food, pet food, aquatic feeds, textured proteins, vegetarian meat, etc;
We will serve the best for you, both quality and technology. Contact me~
