Corn Flakes Cereal Making Machine
The corn flakes cereal making machine was invented by Will Keith Kellogg, an American Doctor of Medicine in Michigan, USA. at the end of 19th century when he was searching a kind of basic food of hygiene vegetarian for fast recovery in patients.
With years of researching and studying the corn flakes cereal making machine technology abroad and invested millions in the R&D of the production technology of the corn flakes cereal making machine, Jinan Eagle Food Machinery Co., Ltd., one of the leading providers of China corn flakes cereal making machine, has successfully developed the high speed double rolling corn flakes cereal making machine and a serial of Corn Flakes Cereal Making Machines that are compatible to the cereal making machine used by the major cereal producers; after we produced a high speed twin-screw extruder of which the capacity is as high as 3000 kg/h.
1.Mixer : Mix the raw material equally
2. Elevator : take the raw material to the extruder
3. Twin screw extruder : mix , cook and extrude the raw material with suitable temp and pressure , first to produce cristal snack balls from the extruder
4. Vibrator : spread the pellet balls to avoid them sticking together
5. Air coveyor : blow the pellet balls to the flaker
6. Flakes machine: Press the snack balls into flakes with adjustable thickness
7. Air conveyor : Blow the corn flakes to the oven
8. Oven : dry the corn flakes to take away most of the moisture content
9. Elevator : take the corn flakes to the next machine
10. Hot air heater : puff the corn flakes to be expanded and crispy
11. Sugar sprayer : spray syrup onto the surface of the corn flakes to make sweet flavor
12.Vibrator : spread the coated corn flakes to avoid sticking together
13. Oven (extended ) : Bake the coated corn flakes to make them crispy again after syrup coating .
14. Cooling conveyor : cool down and convey the corn flakes
Corn flakes is a kind of breakfast with high nutritional value. They usually use corn powder and other cereals as main material. Through mixing, extruding, drying, baking, coating and cooling to get crispy flakes. It always service as breakfast cereal mixed with milk or coffee. but it can also be a kind of leisure snacks.this process line can also make other shapes of cereal such as balls, chocos, curls etc.
Technical Parameters:
Model | Installed Power | Power Consumption | Output | Size(L×W× H) |
DP65 | 140kw | 90kw | 120-150kg/h | 39000x1200x2200mm |
DP70 | 160kw | 120kw | 200kg/h | 41000x1500x2200mm |
DP85 | 190kw | 140kw | 300-400kg/h | 43000x3500x4300mm |
We, Jinan Eagle Food Machinery Co., Ltd are located in the famous industry city-Jinan city, capital of Shandong Province.
As a leading manufacturer of inflating food machinery, we are selling and marketing the machines to many countries in the world. We keep improving our machines and upgrading techniques to satisfy the requirements of all the clients. Depending on our rich experience and professional experts on the extruded food industry, we could offer the most suitable and complete program to assure that your investment will get biggest profit.
Our Systems
At Eagle machinery, we believe each client deserves individualized attention and no process is
stamped as standard. A Eagle system becomes uniquely your system.
In fact, the Eagle line includes 14 different sizes of twin and single screw extruders with capacities from 100 kg/hour to more than 5tonne/hour. Naturally, we offer a choice of dryers/coolers, flavor coating and enrobing systems, and control systems as well. It's just one more reason Eagle has become one of the world's leading suppliers of extrusion cooking systems for grain and food processing.
Our broad range of products makes it possible for Eagle to match the machine(s) to the exact requirements of each customer, whether the application is:
Food - ready-to-eat cereals, pastas, snack foods, breadings, and textured vegetable proteins
Pet Foods and Treats - dry, semi-moist, high meat, co-extruded, multi-colored, novelty shapes
Aquatic Feeds - floating, sinking, slow-sinking, and specialty products
Industrial - biodegradable packing material, oilseed processing, starch-based products, French fries and banana/ plantain chips
WE HAVE OUR MACHINE RUNNING VIDEO FOR YOU ,
PLEASE FEEL FREE TO ASK.
