High nutritional Corn Flakes Processing Line with PLC Control System
Quick Details:
1. Type: Corn flakes machine,corn flakes production line,corn flakes making machine,corn flakesproduction machine,breakfast cereal production line
2. Application: corn flakes, rice flakes, breakfast cereal, Other cereal snacks
3. Processing Types: Breakfast cereal
4. Area Request: Depends on the types of machines
5. Motor: SIMENS
6. Material: Stainless Steel
7. Power: 50-170kw depends on models and fuel
8. Fuel: Electric, Gas, LPG, Diesel
9. Voltage: 3phase/380v/50Hz, or designing according to your local power supply.
10. Control System: PLC
Super quality Corn Flakes Breakfast Cereals Machine 120-400kg
1. Description
Corn flakes/breakfast cereals are a kind of breakfast with high nutritional value.
They usually use corn powder and other cereals as main raw material, through mixing,
extruding,
flaking, drying, baking, coating and cooling,to get crispy flakes. It always service as breakfast
cereal mixed with milk of coffee.
But it can also be a kind of leisure snacks.
This process line can also make other shapes of cereals such as rings, balls, chocos, curls etc
2. Raw materials: corn powder and other cereals
3. Products: corn flakes, rice flakes, breakfast cereal, Other cereal snacks
4. Capacity: 120-150kg/h,200kg/h,300kg/h
5. Flow chart:
Mixer—— Screw conveyor—— Extruder—— Hoister——Dryer——Flaker -- Hoister ——Dryer- - Hot air puff---Sugar coating----Drying----Cooling
6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it
according to customers' Local voltage according to different countries
7. Machines Materials: All the machines are made by 304 stainless
Technical Parameters
Model |
Installed Power |
Power Consumption |
Output |
Size(L×W× H) |
DP65 |
275kw |
193kw |
120-150kg/h |
39000x1200x2200mm |
DP70 |
282kw |
197kw |
200~300kg/h |
41000x1500x2200mm |
Certificate:
CE certificate for this plant.
Terms of Payment:
30% should be paid by T/T as deposit, 70% balance should be paid by T/T before delivery.
Testing & training:
If the machine is exported to other countries, the buyer should be responsible for the round-air tickets, local transportation, board & lodging.
Warranty:
The seller guarantees the quality of the products for 12 months since the date of installation. During the warranty period, any problems/defaults happen on the hard parts of the machinery, the buyer will replace the parts at the seller’s cost (FREE). If the defaults are aroused by the defaulted operations, or the buyer needs the technical assistance for the processing problems, the buyer should be responsible for all the cost and their allowance.
Our factory located in Jinan, Shandong Province, China.
You can take plane to Jinan International Airport, or take high-speed rail to Jinan West
2.What is your payment term?
You can transfer the payment via T/T. Generally, 30% advance to start to produce, 70%
3. What capacity do you want ?
