High Frequency Intelligent digital Lead free soldering
Brand: Wildone 1000A, Lead free soldering station
Power supply: 180w
Input voltage: 220v
Output voltage: 36V
Res. Between tip and ground less than2 Ohm
Vol between tip and ground less than 2mv
Dimension: 180 x 100 x 140mm
Weight: 1.2kg
Temp rise time: 5second
With high frequency eddy current technology, which speeds up the temperature recovery (increase) speed, reduces heat transmit loss, then it has high efficiency saving energy function
With password lock function
With sleeping function, it will decrease to 200 degree Celsius automatically. When using it again, the temperature can increase to the temperature it set previously. The power supply can be off without using in 60 minutes
With high frequency eddy technology, this soldering station and handle is very compact and light
With micro-computer IC control technology, so the output soldering tips temperature is very accurate
Wide application scope, it can use all connecting cords, PCB.with excellent temperature recovery speed, it is very good to use in several layers of PCB, high shielded enclosure & high temperature welding.
There are 5 type of parameter setting mode
1: mode 0: set the current temperature. Seeting range: mode o is 200-400 degree, mode 1 is 50-600 degree
2: mode 1: setting temperature offset: setting range is -50-+50 degree
3: mode 2: setting working mode. Mode o , mode 1
4 mode 3: setting dormancy option
5: mode 4: set and revise the postcode
5: mode 5: exit from setting. Revert to normal working condit
Brand: Wildone 1000A, Lead free soldering station
Power supply: 180w
Input voltage: 220v
Output voltage: 36V
Res. Between tip and ground less than2 Ohm
Vol between tip and ground less than 2mv
Dimension: 180 x 100 x 140mm
Weight: 1.2kg
Temp rise time: 5second
With high frequency eddy current technology, which speeds up the temperature recovery (increase) speed, reduces heat transmit loss, then it has high efficiency saving energy function
With password lock function
With sleeping function, it will decrease to 200 degree Celsius automatically. When using it again, the temperature can increase to the temperature it set previously. The power supply can be off without using in 60 minutes
With high frequency eddy technology, this soldering station and handle is very compact and light
With micro-computer IC control technology, so the output soldering tips temperature is very accurate
Wide application scope, it can use all connecting cords, PCB.with excellent temperature recovery speed, it is very good to use in several layers of PCB, high shielded enclosure & high temperature welding.
There are 5 type of parameter setting mode
1: mode 0: set the current temperature. Seeting range: mode o is 200-400 degree, mode 1 is 50-600 degree
2: mode 1: setting temperature offset: setting range is -50-+50 degree
3: mode 2: setting working mode. Mode o , mode 1
4 mode 3: setting dormancy option
5: mode 4: set and revise the postcode
5: mode 5: exit from setting. Revert to normal working condit
