LCD Separate Machine
1. Auto heating metal plate, maximum temperature is 400 centigrade.
2. Safety power system inside, avoiding the electric leakage problem.
3. Anti static body material, prevent the LCD and the flex cable being damaged from the static
4. 4 stronger arms to press the touch screen glass on the plate
5. Smooth metal plate to hold the touch screen without any damaged.
6. 2 bearings to last long the life of the wire you use to separate, and prevent your hands be hurt
by the high temperature platform
7.K-type thermocouple, close-loop control, stable thermostat
8. Easy installation, fast thermal transmission, high repair efficiency
9.Compatible for LCD or LED screen assembly
10.CE approved
Operation of 2014 Best Choice LCD Digitizer Separate Machine
1. Put your LCD with touch screen on the metal plate, LCD side above
2. Set the 4 arms to keep the touch screen on the metal plate stably
3. Turn on the machine and wait for the metal plate become 70-100 degree
4. Start to separate the LCD off the glass with a core, then right and left movement with the
core in between the LCD and the glass, please notice you must using gentle power and keep
the core stay on the LCD surface, so that it will avoid the touch screen be damaged.
5.Finally you will find yourself do a good job.
Notes of 2014 Best Choice LCD Digitizer Separate Machine
1. Do not produce the heat more than 110 degree when operating; otherwise the high temperature may
destroy the phone accessories
2. As different country has different current or voltage standard, we have Voltage 220V and 110V for
your choice; please choose the right one which meets your country's voltage standard
