Safty and antistatic ESD table mat
Descriptions:
1,It is made of anti-static(conductive) and static-dissipative materials as well as synthetic rubber;
2.The surface layer is a 0.5mm thick static-dissipative layer;
3,The bottom layer is a 1.5mm conductive layer;
4,2mm thick double-layer structure is used.
*Anti-static rubber mat or ground mat should be laid out in the workshops and advanced laboratories for microelectronic industries such as electronic semi-conduct devices, electronic computers, electronic communication equipment and integrated circuits etc.
*To eliminate damages caused by static electricity.
When anti-static rubber mat (ground mat) are laid out and grounded, the working surface will discharge the static electricity of human bodies so that a near-equipotential can be maintained for ESD tweezers, tools, utensils and instruments, through which human bodies contact the working table and static sensitive devices(SSD) are free from broadband interference produced by static discharging such as triboelectrification etc. In this way, electrostatic protection is realized.
Specifications:
| Resistivity of Surface Layer | 10E6-10E9Ω |
| Resistivity of Bottom Layer | 10E3-10E5Ω |
| Bulk Resistivity | 10E5-10E8Ω |
| Abrasiveness Loss | <0.02g/cm2 |
| Size | 10mx1.0m, 10mx1.2m,10x0.8m |
| Color | Green/Black.Blue/Black,Grey/Black |
| Time for static dissipation | <0.1s |
| thickness | 2.0mm, 2.5mm, 3.0mm |
Detail Images:
1,Good quality and competitive price.
2.Fully range of products for choose.
3.Any doubts, contact us.
