Home > Products > Electronic Screwdriver & digital torque meter > HDP series Intelligent Digital Torque meter , for high precision
HDP series Intelligent Digital Torque meter , for high precision
- 100000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Willdone | Model Number: | / |
Power: | Electronic | Usage: | Torsion Tester |
Product Description
HDP series Intelligent Digital Torque meter , for high precision
Specifications
Model | HP-5 | HP-50 | HP-100 | |
Measurement Range | Kgf.cm | 0.03-5.0 | 0.15-50.0 | 0.2-100 |
N.m | 0.015-0.5 | 0.015-5.0 | 0.2-10.0 | |
lbf.in | 0.03-4.8 | 0.15-50.0 | 0.2-100.0 | |
Accuracy | within ±0.5% | |||
Detector Bit Socket | H4 or 1/4 HEX,H5 or 1/4 HEX | |||
Dimensions | Display Unit165(W)*95(D)*55(H) |
Applications
1,Specially designed for managegemt of torque for tightening screws;
2,Memory function makes saving and managing of torque data possible;
3,The maximum torque,the minimum torque,and the average torque torque can be confirmed by Ave measurement function;
4,First peak measuring mode(F.PEAK) gives precision measurements of torque wrenches or other tools;
5,Automatically recalibrated to zero value;
6,For testing breakdown of small parts;
7,For quality control of plastic screws and parts.
