ZB800-2A Auto Rendering Machine /Automatic Rendering Machine

wooden cases

Specifications

Features:
1.Auto Plastering Machine
2. Save cost: 70%
3.20 times faster than manual rendering
4. Efficiency:500-750m2/8 hour

Auto Rendering Machine



General Introduction:



We are professional manufacturer of  Auto Rendering Machine . ZB800-2A  Auto Rendering Machine also called plaster machine, wall plastering machine, automatic plastering machine, plastering machine for wall, which is a unique machine for wall rendering, it is designed for increasing rendering efficient and saving labor cost of rendering project.



Main Features:



1. Auto Rendering Machine
2. Save cost: 70%

3.20 times faster than manual rendering
4. Efficiency:500-750m²/8 hour



More Information:



1. It is new machine instead of handmade in construction plastering area.

2. The capacity is as 15 professional plasterers.

3. The quality is subject to international wall plastering standard.

4. Very easy and simple to operation

5. Saving more than 20% raw material (cement &sand)



6.It can plaster the wall automatically and go up and down automatically.



7.It can plastering by one-time.The thickness of the ash can be adjusted.



8.Easy to move,without removing any parts of the machine.



9.It has large capacity hopper,you can put the ash/lime/gypsum in it one-time.



Technical data:

ZB800-2A Technical data
Plastering Height	0-5meters
Plastering Thickness	2-25mm
Plastering Width	80cm
Capacity	450 square meters/8 hours
Dimensions	1350×800×500mm
Power supply	2.2kw
Voltage/frequency	According to your demands
Weight	195KG
Surface	smooth
Vibrator	Yes
Juncture device	Yes
Smoothing knife	Yes
storage capacity	90-100KG
Perpendicularity degree	≤2mm
Level degree:	≤2mm



Auto Rendering Machine VS Manual Work





 Applications:



• Application on brick or block walls

• Render cement mortar

• Render gypsum mortar

• Render lime mortar

• Render ready mix



The process of plaster the wall



Step 1.fix the machine





Step 2. load ash





Step 3. go up to the first plastering





Step 4. go down for the first smoothing





Step 5. the first section of plastering wall is finished





Step 6.repeat step1-5



Time Sheet

Step2	Assemble machine	120 seconds
Step3	Move the machine to the wall for rendering	20 seconds
Step4	Adjust the vertical and horizontal level	20 seconds
Step5	Load any kind of suitable mixture to tank	30 seconds
Step6	Render one section 800 mm	60 seconds*



Remarks: * means the time of rendering up to 3 m height of wall with 800 mm width for one section



More pictures:
