passenger elevator with elevator flooring options

1

Full collective selective control

15

Overload protection

29

Anti-jam door opening protection

2

Inspection mode

16

Overspeed protection

30

Curtain of light

3

Car call

17

Time controlling

31

Door -closing outside door zone

4

Automatic rescue traveling

18

Antiskid protection

32

Floor indication

5

Automatic door opening

19

Final limit switch protection

33

Running indication of floor

6

Automatic door closing

20

Automatic detection of bread contacting point

34

Reversal car call clear

7

Communication system error protection

21

Frequency converter protection

35

Auto return base in fire emergency

8

Fire alarm

22

Indication of times of travel

36

Auto landing

9

Door -closing button for advance door closing

23

Low-voltage protection

37

Auto correction of floor position signal

10

Door opening button

24

Phase protection

38

Self learning of hoist way

11

Door re-opening

25

Emergency lighting

39

False call cancel

12

Starting compensation

26

Door lock protection

40

Reversal running protection

13

Full load bypass

27

Shift of leveling

41

History record of trouble

14

Automatic turn off lighting and fan

28

Error code

Load(kg)

Number of Passenger

Speed(m/s)

Size Inside the Cabin

Entrance Opening Width

450

6

1.0/1.5

1400×900

800

630

8

1.0/1.5/1.75

1400×1200

800

800

10

1.0/1.5/1.75/2.0/3.0

1400×1400

800

1000

13

1.0/1.5/1.75/2.0/3.0

1600×1500

900

1250

16

1.0/1.5/1.75/2.0/3.0

2000×1400

1000

1350

18

1.0/1.5/1.75/2.0/3.0

2000×1500

1100

1600

21

1.0/1.5/1.75/2.0/3.0

2000W×1700H

1200

Load(kg)

Hoistway Dimension

Machine Room Dimension

Pit Depth(m)

Overhead(m)

450

2000×1600

2000×1600

1.5/1.6

4.3/4.4

630

2000×1900

2000×1900

1.5/1.6/1.7

4.3/4.4/4.5

800

2000×2100

2000×2100

1.5/1.6/1.7/1.8/2.5

4.3/4.4/4.5/4.8/5.0

1000

2200×2200

2200×2200

1.5/1.6/1.7/1.8/2.5

4.3/4.4/4.5/4.8/5.0

1250

2600×2100

2600×2100

1.5/1.6/1.7/1.8/2.5

4.3/4.4/4.5/4.8/5.0

1350

2600×2200

2600×2200

1.5/1.6/1.7/1.8/2.5

4.3/4.4/4.5/4.8/5.0

1600

2600×2450

2600×2450

1.5/1.6/1.7/1.8/2.6

4.3/4.4/4.5/4.8/5.0
