Our main products are refrigerated truck and body, dry truck and box,dump truck and body,foton truck.
We choose the best product to the customer.
We are looking for long term cooperation with customer. Therefore, if there is any quality feedback, we shall provide technical support and after sales service promptly. Easy to wear off parts list for each model is available upon customer's request. Service parts shall be sent along with each complete truck as well to ensure easy maintenance and service of each truck.
Note: The cab, engine, gearbox, tire,color,cargo body size and others have options.
1 Due to improvements made to the product, data herein is subject to change without notice.
2. Different outfits are provided for the different configurations of the motor vehicles.
3. Affected by the reproduction conditions, the pictures and data differ somewhat from the actual motor vehicles.
4. JOYFLY reserves the rights to make final explanations
| Vehicle Model | ||
| Drive line | 4x2 | |
| Cabin | full-floating, hydraulic tilt | |
| Engine | Model | CA4DC2-10E3 |
| Displacement (L) | 3 . 168 | |
| Power (HP) | 100HP | |
| Min. fuel consumption(g/(kW@h) | ||
| Clutch | single plate, dry, diaphragm | |
| Gearbox | Model | CA5-48 |
| Ratio (reverse) | ||
| Rear Axle | Model | FAW 1058 Single reduction , 5.571 |
| Steering | power steering | |
| Brake system | dual circuit air brake | |
| Electrical equipment | 24V, Single line, negative grounded |
|
| Wheel & tyre | 7.00-1612 | |
| Track (F/R) | 1 600 /1 485 | |
| Wheelbase (mm) | 3260 | |
| Overhang (F/R) | 1 241 / 1497 | |
| Max. Speed | 9 8 | |
| Max. Grade ability | 30% | |
| Overall Size (mm) | 5998x2100x2375 | |
| Cargo body size (mm) | 4200x2000x400 | |
| Curb Weight (kg) | 2560 | |
| Gross Veh i cle Weight (kg) | 4495 | |
STANDARD FEATUES:
Radio, cassette, MP3 player with USB input, Front slip & adjustable seat, Heater, 2 speakers, Steel wheel rim, Exterior mirror with body color, Front combination lamp, Folding key, Mechanical combination meter, Double-color knitted decoration, Interior fuel tank opener, 4-spoke steering wheel, Ashtray & lighter, Folding cup holder, Fog lamp, Seat belt, Steering column lock, Black front bumper, Un-folding key
OPTIONAL FEATUES:
Front A/C, Aluminum-alloy wheel rim, Exterior mirror with body color, Electronic combination meter, Front bumper with same color with body, Right hand drive, CNG/gasoline dual fuel engine (1.0L), LPG/gasoline dual fuel engine(1.0L), Electric power steering, ABS, Airbag for driver & co-driver
