Scrolling Advertising Trucks Mini Electric Cargo Truck
US$ 5,000 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
foton
Model Number:
BJ1039V4JD3-F
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao/tianjin/shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Dongfeng Mini Truck Jac Brand New Refrigerator TruckUS$ 5,000 - 8,000MOQ: 1 Set -
1 10 Electric 4wd rc Touring Car 4x2 Van TruckUS$ 5,000 - 8,000MOQ: 1 Set
-
Small Flatbed Truck 6x4 Dongfeng Cargo TruckUS$ 5,000 - 8,000MOQ: 1 Set
-
Perimeter Advertising Led Display Beekeeping EquipmentUS$ 5,000 - 8,000MOQ: 1 Set
-
Right Hand Driving Flatbed Truck Mini Freezer VanUS$ 8,000 - 10,000MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
foton
Model Number
BJ1039V4JD3-F
| Vehicle brand | AUMARK C | |
| Vehicle model | BJ1039V4JD3-F | |
| Cabin | Single row seat tiltable | |
| Wholevehicle main cargo body (LxWxH)mm | Overall dimensions | 4955×1900×2240 |
| (LxWxH)mm | 4890×1820×2700 | |
| Inner dimensions of the | 3200×1810×380 | |
| Driving type | 4×2 | |
| Wheel base | 2600 | |
| Wheel track (front/rear) | 1490/1425 | |
| Min. ground clearance | ≥180 | |
| Weight data | Curb weight | 1940(Chassis)2300(CBU) |
| Rated payload (kg) | 1070 | |
| Persons in cab | ||
| Gross vehicle weight | 3500 | |
| Whole | Max. speed(km/h) | 110 |
| vehicle main | Max. slope of climb | 0.3 |
| performance | Fuel consumption | 9.6 |
| Min. turning diameter | 13 | |
| Engine | Model | ISF2.8s4107P (EuroIV) |
| Four-cylinder,In-line | ||
| Type | stroke,Water-cooling, | |
| turbocharging middle cooling | ||
| Displacement(L) | 2.78 | |
| Rated power(kw/rpm) | 80/3600 | |
| Max torque | 280/1400~2400 | |
| Gearbox | Model | 5S400 |
| Speed ratio | ||
| 9/4.481 | ||
| Clutch | Type | diaphragm springφ310×φ190 |
| Rear axle | Type/Main reducer ratio | Whole banjo type,Speed |
| ratio:4.875 | ||
| Suspension | Front suspension/Leaf | non-independent suspension, |
| spring number | leaf spring/3 | |
| Rear suspension/Leaf | non-independent suspension, | |
| spring number | leaf spring/6 | |
| Steering gear | Circular ball type,Power | |
| steering | ||
| Brake system |
Service brake | frontradiusR108cylinder:hydraumaticdick,rear,working:doubledrum |
| Parking brake | Centrab k drum brake | |
| Auxiliary brake | —— | |
| Wheels and tyre size | 6.50R15 | |
| Electric | Rated voltage | 12V |
| Fuel tank (L) | 80L | |
| A/C,Heater,Clutch | ||
| Basic equipment | booster,Adjustable steering | |
| wheel,Power steering,cruise | ||
| option | ||
| controlBasic lock+Electro-drivenequipment+Center | ||
| radar+ABS+PTO+loadinglifter+radio+CD+reversewindow glass | ||
STANDARD FEATUES:
Radio, cassette, MP3 player with USB input, Front slip & adjustable seat, Heater, 2 speakers, Steel wheel rim, Exterior mirror with body color, Front combination lamp, Folding key, Mechanical combination meter, Double-color knitted decoration, Interior fuel tank opener, 4-spoke steering wheel, Ashtray & lighter, Folding cup holder, Fog lamp, Seat belt, Steering column lock, Black front bumper, Un-folding key
OPTIONAL FEATUES:
Front A/C, Aluminum-alloy wheel rim, Exterior mirror with body color, Electronic combination meter, Front bumper with same color with body, Right hand drive, CNG/gasoline dual fuel engine (1.0L), LPG/gasoline dual fuel engine(1.0L), Electric power steering, ABS, Airbag for driver & co-driver
