Specifications
truck box body panels/frp truck body panels
1,military technology
2,3C certificate
3,Easy Installation
4,export 20country
1.Products of our factory: Aluminum truck box body panels/frp truck body panels
Truck body from FRP honeycomb panel
We can supply: refrigerated truck body, insulated truck body, dry cargo truck body, plateform truck body, explosion-proof truck body, dump truck body,tank truck body, wing opening truck body, catering truck body, any other special purpose truck and truck body.....etc
The refrigerated truck body proecessed with FRP with insulation foam. Our standard thickiness is 100mm. But the thickness can be change according to customer's requirements.
Stainless steel door frame and door lock system.
2, Aluminum truck box body panels/frp truck body panels Main Characters
Light in weight: 40% lighter than metal body.
Better insulation: K value less than 0.3w/m2k.
High in strength and long life: 5 times longer than metal body.
Non-corrosion, non-pollution, anti-brine, acid and soda-resisting.
Easy to assembly and repair at site.
3, Aluminum truck box body panels/frp truck body panels can be chosen at the follow range:
Length 0-15000mm
Width 0-3100mm
Thickness 25-135mm
4,Our products have been widely exported to India, Philippines, Pakistan, Yemen, Singapore, Hong Kong, Thailand, Uzbekistan, Peru, Australia, New Zealand, Tanzania as well as many other countries in Middle East, Southeast Asia, South America and Africa
Aluminum Truck Bodies refrigerated cold room van truck
1) Germany technique
2)easier installation:pu foam,FPR,
3)Sandwich panel assembly
4) -18-20 degree
LENGTH |
2495mm |
||
WIDTH |
1850mm |
||
INTERNAL HEIGHT |
1200mm |
||
WEIGHT (Approx.) |
600kg |
||
PALLET LOADING |
2 Pallet Capacity |
||
FIT OUT |
|
|
|
SIDE DOOR |
Single 750 x 1100mm, opens to left |
||
REAR DOOR |
Double doors, opens left first |
||
REAR STEP |
50mm deep rear step finished with checker |
||
|
|
plate |
|
FLOOR |
Heavy duty fully welded extruded |
||
|
|
aluminum H -floor, 200mm aluminum |
|
|
|
extruded kick plate |
|
ROOF THICKNESS |
70mm |
||
FLOOR THCIKNESS |
100mm
|
||
STANDARD FEATURES
• Thermal breaks on all doors
• Fibreglass and polyurethane foam panel with internal ribbing
• Full span steel sub-frame
• LED internal light with switch on internal wall
• All stainless steel hardware
• Stainless steel rear door frame
• Rear door gutter
• Stainless steel rear grab handles
• Aluminum drain pipe with duck bill
• Rear dock rubbers
• Mudguards
• LED clearance lights
Model: CY30N 3.0m SPECIFICATION SHEET
DIMENSIONS
Out LENGTH 3050mm
Out WIDTH 2100mm adjust to 2050
INTERNAL HEIGHT 1780mm
WEIGHT (Approx) 1000kg
FIT OUT
SIDE DOOR Single 750 x 1700mm, opens to left
SIDE DOOR STEP Single rung
REAR DOOR double rear door
REAR STEP 150mm deep rear step finished with checker plate
CARGO TRACK Stainless steel, 1 row of @ 750mm with one shoring bar in holder
FLOOR checked 2.0m aluminum floor, 200mm aluminum extruded kick plate
STANDARD FEATURES
• Thermal breaks on all doors
• Fibreglass and polyurethane foam panel with internal ribbing
• Full span steel sub-frame
• LED internal light with switch on internal wall
• All stainless steel hardware
• Stainless steel rear door frame
• Rear door gutter
• Stainless steel rear grab handles
• Aluminum drain pipe with duck bill
• Rear dock rubbers
• Mudguards
• LED clearance lights
Model: CY39N3 3.9m
DIMENSIONS
Out LENGTH 3900mm
Out WIDTH 2300mm
INTERNAL HEIGHT 2050mm adjust 2200mm
WEIGHT (Approx) 1200kg
FIT OUT
SIDE DOOR Single 750 x 1800mm, opens to left
SIDE DOOR STEP Single rung
REAR DOOR three doors – left two doors,
REAR STEP 150mm deep rear step finished with checker plate
CARGO TRACK Stainless steel, 1 row of @ 750mm with one shoring bar in holder
FLOOR checked 3.0m aluminum floor, 200mm aluminum extruded kick plate
STANDARD FEATURES
• Thermal breaks on all doors
• Fibreglass and polyurethane foam panel with internal ribbing
• Full span steel sub-frame
• LED internal light with switch on internal wall
• All stainless steel hardware
• Stainless steel rear door frame
• Rear door gutter
• Stainless steel rear grab handles
• Aluminum drain pipe with duck bill
• Rear dock rubbers
• Mudguards
• LED clearance lights
cool box. refrigerator box
